ማጠቃለያ
የ HOWO 40 ቶን ቡም አንደርሊፍት የተለየ ተጎታች መኪና is a powerful and versatile road rescue vehicle engineered to excel in towing, recovery, and transportation operations. Featuring a combination of lifting winch equipment, wheel brackets, and hydraulic systems, this tow truck is an essential asset for swiftly clearing accidents, ብልሽቶች, and illegal vehicles from roadways. Designed for diverse scenarios, from police traffic control to airports and auto repair companies, this tow truck offers reliable and efficient solutions for keeping roadways safe and traffic flowing smoothly.
ይህ ተጎታች መኪና stands as a powerful solution for road rescue, recovery, እና መጓጓዣ. With its advanced features, engineering excellence, and versatile capabilities, it emerges as a crucial asset in maintaining road safety, የትራፊክ አስተዳደር, and efficient vehicle recovery operations.
Features
Versatile Functionality:
- Equipped with lifting winch devices and wheel brackets, the tow truck can perform tasks such as lifting, towing, back-loading, and transporting.
- Widely used across various domains, including road management, police traffic control, አየር ማረፊያዎች, ወደቦች, auto repair companies, industry, and highway departments.
- Efficiently addresses accidents, failures, illegal vehicles, and road blockages, ensuring timely and effective vehicle removal.
Advanced Engineering:
- Comprised essential components including the chassis, hoisting equipment, truck tow hook, tow truck winch, tow truck wheel lift, የሃይድሮሊክ ስርዓት, electric control system, truck body, and toolboxes.
- Sinotruck HOWO HW76 cabin with power steering, A/C, and right-hand drive for operator comfort and control.
- Gearbox: Manual Synchromesh HW19710, 10-speed forward + 2 የተገላቢጦሽ.
- ሞተር: WD615.47, 371hp, water-cooled diesel engine with emission controls.
- Braking system: Air over hydraulic dual circuit system, park brake with mechanical, internal expanding acting on the transfer output shaft.
Powerful Tow and Recovery Capabilities:
- Hydraulic-operated 3-telescope boom with a retracted capacity of 40,000 kg and extended capacity of 6,500 ኪ.ግ.
- Lifting height of 12,250mm with power elevation and power extension.
- Dual hydraulic pump, 360-degree sheave heads, and hydraulic outriggers with power elevation and extension.
- Dual hydraulic winches with a total capacity of 20,000 ኪ.ግ, each equipped with steel cables of 60m length and 20mm diameter.
- Hydraulic under the lift at the rear with varying capacities for retraction and extension, a towing capacity of 40,000 ኪ.ግ.
Safety and Control:
- Auto brake for winch ensures automatic safe brake operation in case of winch or engine failure.
- Necessary hydraulic pressure relief and lock valves for enhanced safety during operations.
- Wrecker operation panel board with joysticks and hydraulic meters for ease of control and monitoring.
ሁለገብ መተግበሪያዎች:
- Wrecker tow truck serves the purpose of moving disabled, improperly parked, impounded, or incapacitated motor vehicles.
- Addresses various scenarios including recovering accident-damaged vehicles, returning vehicles to drivable surfaces during mishaps or inclement weather, and transporting vehicles to repair shops or designated locations.
ዝርዝሮች:
| Truck Specification | |||
| Truck model | |||
| ካብ’ዚ ንላዕሊ’ዩ ዝበጽሖ | Sinotruck HOWO HW76 cabin ,, with power steering., with a/c,right hand drive | ||
| Driving Type | 8*4 | ||
| Max Speed (ኪሜ በሰአት) | 90 | ||
| Overall dimension(ሚ.ሜ) | 10685*2500*3460 | ||
| Mass in working order( ኪ.ግ) | 19525 | ||
| GVW( ኪ.ግ) | 31000 | ||
| የዊልቤዝ(ሚ.ሜ) | 1800+4600+1350 | ||
| F/R track base(ሚ.ሜ) | 2022/1830 | ||
| F/R overhang(ሚ.ሜ) | 1500/880 | ||
| Approach/Departure Angle | 16/10 | ||
| Tire | 12.00R20(10+1) | ||
| ክላች | Single plate friction type with an air booster system | ||
| መሪነት | Power-assisted steering. | ||
| Gearbox | Manual Synchromesh HW19710, 10 SPEED FORWARD +2REVERSE |
||
| Bridge | Front axle | HF9 | |
| Rear axle | HC16 | ||
| ሞተር | ሞዴል | WD615.47 | |
| ዓይነት | cylinder water-cooled diesel engine to be fitted with diesel particulate filter in-built. | ||
| Exhaust(ml) | 9726 | ||
| Max output power/rotation speed (hp /rpm ) | 371/2200 | ||
| Max torque/rotate speed(N.m/rpm) | 1500/1100-1600 | ||
| Braking system | Service Brake | Air over hydraulic dual circuit system | |
| Park Brake | Mechanical, internal expanding acting on the transfer output shaft | ||
| Electric system | 24v | ||
| Upper-Body specification | |||
| Wrecker Type | Hydraulic operated 3 telescope boom | ||
| Boom structure | Retracted – 40,000 ኪ.ግ | ||
| Extended – 6,500 ኪ.ግ | |||
| Lifting height:12250ሚ.ሜ | |||
| power Elevation | |||
| Power Extension | |||
| Dual Hydraulic Pump | |||
| 360-degree sheave heads | |||
| Hydraulic Outriggers | 4 in-built with power elevation & extension. | ||
| Hydraulic winches & steel cables | Dual, 20,000 kg x 2-Planetary type Cable Type: Steel cable60m length, 20mm diameter |
||
| Power take-off | PTO drive from the transmission | ||
| Wrecker Operation | Panel board comprising joysticks and hydraulic meters installed in a suitable place out of the crew cabin. | ||
| Hydraulic System | Suitable capacity gear pumps for boom movement, telescoping cylinder, የኃይል መሪ, and control valves & control system shall be with adequate size oil reservoir, integral oil cooler, ቫልቮች, ወዘተ. | ||
| Hydraulic Under Lift at Rear | · Fully retracted 20000 ኪ.ግ · Fully extended 9,000 ኪ.ግ · Under Lift- 10° – 15 · Towing capacity: 40000kgs |
||
| Safety Device | |||
| Auto brake for winch | Automatic safe brake in case winch / Engine fails. | ||
| Hydraulic valves | Necessary hydraulic pressure relief & lock valve/ valves | ||
