BREF
Le 12-wheeler 16-ton grue à flèche articulée par Grue de remorquage CSCTRUCK is a robust and versatile machine designed for heavy-duty lifting tasks. Built on a sturdy COMMENT chassis with an 8×4 drive type, this crane ensures exceptional stability and mobility, even in challenging terrains. The crane is equipped with 3 extensions de flèche hydrauliques, providing a maximum hydraulic outreach of 10 mètres. This capability, combined with a 49-meter-ton lifting moment, allows for precise and efficient handling of heavy loads.
Le grue à flèche articulée boasts a maximum lifting capacity of 16,000 kilogrammes, making it suitable for a wide range of industrial applications, de la construction à la logistique. It features a slewing angle of 400 degrees and a slewing torque of 5.5 meter-tons, which ensures smooth and flexible maneuverability around the work site. This extensive slewing range facilitates the positioning of loads with minimal repositioning of the vehicle, Amélioration de l'efficacité opérationnelle.
To support its heavy lifting capabilities, the crane operates at an impressive pump capacity of 55-80 liters per minute and an operating pressure of 33 MPa. These specifications ensure a steady and powerful hydraulic flow, enabling the crane to perform demanding tasks consistently. The standard crane weight of 4,750 kilograms indicates a well-balanced design that does not compromise on structural integrity or safety.
Dans l'ensemble, le Grue de remorquage CSCTRUCK‘s 16-ton grue à flèche articulée is a reliable and high-performance machine, engineered to meet the rigorous demands of heavy lifting operations with precision and durability.
CARACTÉRISTIQUES
1. Powerful Lifting Capability:
– Capacité de levage maximum: 16,000 kg.
– Lifting Moment: 49 tonnes métriques.
2. Versatile Boom Functionality:
– Hydraulic Boom Extensions: 3 extensions.
– Max Hydraulic Outreach: 10 mètres.
3. Robust Chassis and Drive System:
– Châssis: HOWO chassis.
– Type de lecteur: 8×4, providing excellent traction and stability.
4. Efficient Hydraulic System:
– Pump Capacity: 55-80 litres par minute.
– Operating Pressure: 33 Megapascals (MPa).
5. Extensive Slewing Capability:
– Slewing Angle: 400 degrés, allowing for a wide range of motion.
– Slewing Torque: 5.5 tonnes métriques, ensuring smooth and powerful rotation.
SPÉCIFICATION
| Article | Unité | CSCKBC50002B | CSCKBC50002C | CSCKBC50002D | CSCKBC50002E |
| Hydre. rallonges de flèche | / | 3 | 4 | 5 | 6 |
| Moment de levage | mont | 49 | 49 | 49 | 49 |
| Max. capacité de levage | kg | 16,000 | 15,790 | 15,200 | 14,200 |
| Max. portée hydraulique | m | 10 | 12.1 | 14.5 | 16.8 |
| Angle de rotation | ° | 400 | 400 | 400 | 400 |
| Couple de rotation | mont | 5.5 | 5.5 | 5.5 | 5.5 |
| Capacité de la pompe | L/min | 55-80 | 55-80 | 55-80 | 55-80 |
| Pression de service | Mpa | 33 | 33 | 33 | 33 |
| Poids standard de la grue | kg | 4,750 | 4,950 | 5,180 | 5,400 |
| Portée des stabilisateurs(mm) | R3X | 6,600 | 6,600 | 6,600 | 6,600 |
