BREF
Le 6-wheeler 10-ton truck telescopic crane produced by CSCTRUCK Tow Crane is a robust and versatile machine designed for heavy-duty lifting and transportation tasks. This model features a 4×2 drive type, ensuring reliable performance on various terrains and operational conditions.
With a rated lifting capacity of 10,100 kg, the crane is capable of handling substantial loads, making it suitable for construction, logistique, and industrial applications. The crane boasts a maximum working radius of 13.69 mètres, which allows it to operate effectively over a wide area. En plus, it has a maximum lifting height of 15.6 mètres, facilitated by its 4-section boom, enabling it to reach considerable heights for tasks such as building maintenance, material lifting, and installation work.
Le truck telescopic crane‘s stability is enhanced by a 5.7-meter outrigger span, ensuring safe and secure operations during lifting tasks. It can perform consecutive 360° turns, providing exceptional maneuverability and operational flexibility. The turning speed of 2.0 rotations per minute (rmp) further contributes to its efficiency in completing tasks swiftly and accurately.
De plus, the crane is equipped with a 120-liter hydraulic oil tank, ensuring sustained and powerful hydraulic operations. This feature is crucial for maintaining the performance of the crane’s lifting and turning mechanisms over extended periods.
Overall, le CSCTRUCK Tow Crane’s 6-wheeler, 10-ton truck telescopic crane is a highly capable and reliable machine, designed to meet the demanding requirements of modern lifting and transportation needs. Its combination of lifting capacity, reach, stability, and maneuverability makes it a valuable asset in any heavy-duty operational environment.
CARACTÉRISTIQUES
1. High Lifting Capacity and Range:
– The crane has a rated lifting capacity of 10,100 kg, making it suitable for heavy lifting tasks. It features a maximum working radius of 13.69 meters and a maximum lifting height of 15.6 mètres, providing considerable reach and height for various lifting operations.
2. Robust Telescopic Boom:
– Equipped with a telescopic boom that includes 4 sections, this crane can extend and retract to adjust the boom length as needed, enhancing its versatility in different lifting scenarios.
3. Stable and Safe Operation:
– The crane has a 5.7-meter outrigger span, which ensures stability during lifting operations. The outriggers provide a wide base, reducing the risk of tipping over during heavy lifts.
4. Full Rotation and Controlled Speed:
– Capable of consecutively turning 360 degrés, this crane offers complete rotational flexibility, allowing operators to position loads precisely. It has a turning speed of 2.0 revolutions per minute (tr/min), ensuring smooth and controlled movements during operations.
5. Efficient Hydraulic System:
– The crane is equipped with a 120-liter hydraulic oil tank, supporting its hydraulic system to operate efficiently. The hydraulic system powers the boom extension, retraction, and other crane movements, ensuring reliable and powerful performance.
SPÉCIFICATION
| Basic data | CSCTTC1004-1 |
| Capacité de levage nominale | 10,100kg |
| Moment de levage nominal | 10,100*2.5m |
| Max. working radius | 13.69m |
| Max. hauteur de levage | 15.6m |
| Boom section | 4 |
| Outrigger Span | 5.7m |
| Turning angle | Consecutively turn 360° |
| Turning speed | 2.0 rmp |
| Hydraulic oil tank capacity | 120L |
