BREF

CARACTÉRISTIQUES

• Avec une capacité de charge de 6 tonnes, this truck is capable of handling substantial weights. It can transport heavy equipment, tools, and materials to various job sites, ensuring efficient workflow.
• The robust construction and high-capacity chassis make it suitable for demanding tasks in construction, services publics, and other industries.

• The articulated design allows for excellent maneuverability in tight spaces and on uneven terrain. The truck can turn on a dime, making it ideal for working in congested urban areas or on construction sites with limited space.
• The flexible joint between the cab and the chassis enables the truck to navigate around obstacles and access hard-to-reach areas, increasing its versatility and productivity.

• The bucket lift system is a key feature of this truck. It provides a safe and stable platform for workers to access heights for tasks such as tree trimming, electrical maintenance, and signage installation.
• The bucket can be raised and lowered smoothly, with adjustable height and angle settings to meet different work requirements. The lift mechanism is powered by a reliable hydraulic system, ensuring quick and precise operation.

• Jmc is known for its quality construction, and this truck is no exception. The chassis, body, and components are built to withstand heavy use and harsh working conditions.
• The truck is designed for long-term durability, with features such as reinforced frames, high-quality materials, and reliable mechanical and electrical systems. This ensures minimal downtime and maximum productivity.

• The cab of the Jmc 6 Ton Articulated Bucket Lift Truck is designed for operator comfort and safety. It features a spacious interior, ergonomic seating, et une bonne visibilité.
• The truck is equipped with safety features such as rollover protection, seat belts, and emergency stop buttons to ensure the well-being of the operator. En plus, the bucket lift system has safety locks and overload protection to prevent accidents.

• This truck can be customized to meet specific job requirements. It can be fitted with different attachments and accessories, such as toolboxes, treuils, and lighting systems.
• The versatility of the Jmc 6 Ton Articulated Bucket Lift Truck makes it suitable for a wide range of applications, from construction and maintenance to utilities and landscaping.

SPÉCIFICATION

Informations de base
Formulaire de lecteur	4X2
Empattement	3360mm
Taper	Chariot élévateur à godets articulé
Vehicle size	7.56X2X2.995 meters
Masse totale	5.965 tonnes
Poids du véhicule	5.64 tonnes
Porte-à-faux avant/porte-à-faux arrière	1.075/2.095 mètres
Voie avant/voie arrière	Front： 1370mm; Rear：1440mm
Engine parameters
Modèle de moteur	Jiangling JX4D30B6H
Déplacement	2.892L
Puissance de sortie maximale	85kW
Puissance maximale	116 puissance
Norme d'émission	Euro VI
Transmission parameters
Modèle de transmission	Jiangling 5MTI280Y
Nombre de vitesses	5 engrenages
Chassis parameters
Marque de châssis	Jiangling Motors
Série de châssis	New Shunda narrow body
Modèle de châssis	JX1061TSGA26
Nombre de ressorts à lames	4/5+6
Pneus
Nombre de pneus	6
Spécification des pneus	7.00R16LT 12PR.
