BRIEF
Tá an SHACMAN M3000S 23-ton knuckle boom crane, manufactured by CSCTRUCK Tow Crane, represents a robust solution for heavy lifting and versatile operations. With its impressive specifications, the crane is equipped with 3 hydraulic boom extensions, offering a maximum lifting capacity of 23,000kg and a substantial lifting moment of 70.1mt, ensuring it can handle demanding loads with ease.
Designed for flexibility, the crane boasts a maximum hydraulic outreach of 9.4 meters and a slewing torque of 7mt, enabling precise positioning of loads across various work sites. The hydraulic system is capable, with a pump capacity ranging from 80 chuig 100 liters per minute and an operating pressure of 35Mpa, ensuring efficient and reliable performance under different operational conditions.
Despite its robust capabilities, an SHACMAN M3000S knuckle boom crane maintains a manageable weight of 6,093kg in its standard configuration, enhancing its mobility and ease of transport between job sites. This balance of strength and agility makes it suitable for a wide range of applications, from construction and infrastructure projects to logistics and heavy industry.
In summary, an SHACMAN M3000S 23-ton knuckle boom crane le CSCTRUCK Tow Crane stands out for its high lifting capacity, extended reach, and durable construction, making it a preferred choice for professionals seeking reliability and efficiency in heavy-duty lifting operations.
FEATURES
1. High Lifting Capacity:
– The crane boasts an impressive maximum lifting capacity of 23,000kg, making it suitable for heavy-duty lifting operations.
2. Extended Hydraulic Outreach:
– With a maximum hydraulic outreach of 9.4 meters, the crane can reach considerable distances, enhancing its versatility in various applications.
3. Powerful Lifting Moment:
– The crane features a substantial lifting moment of 70.1 metric tons(mt), indicating its capability to lift heavy loads at extended reaches safely.
4. Efficient Hydraulic System:
– Equipped with a hydraulic pump capacity of 80-100 liters per minute and an operating pressure of 35 megapascals(Mpa), the crane ensures efficient and powerful hydraulic performance.
5. Robust and Stable Construction:
– The crane has a standard weight of 6,093kg and features a slewing torque of 7 metric tons (mt), providing stability and strength during operations. This makes it reliable for demanding tasks and enhances its operational safety.
SPECIFICATION
| Item | Unit | CSCKBC74002B | CSCKBC74002C | CSCKBC74002D | CSCKBC74002E | CSCKBC74002F | CSCKBC74002G |
| Hydr. boom extensions | / | 3 | 4 | 5 | 6 | 7 | 8 |
| Lifting moment | mt | 70.1 | 70.1 | 70.1 | 70.1 | 70.1 | 70.1 |
| Max. lifting capacity | kg | 23,000 | 23,000 | 22,000 | 21,500 | 21,000 | 20,500 |
| Max. hydraulic outreach | m | 9.4 | 11.4 | 13.6 | 15.7 | 18 | 20.3 |
| Slewing angle | ° | endless | endless | endless | endless | endless | endless |
| Slewing torque | mt | 7 | 7 | 7 | 7 | 7 | 7 |
| Pump capacity | L/min | 80-100 | 80-100 | 80-100 | 80-100 | 80-100 | 80-100 |
| Operating pressure | Mpa | 35 | 35 | 35 | 35 | 35 | 35 |
| Standard crane weight | kg | 6093 | 6401 | 6798 | 7091 | 7314 | 7514 |
| Outrigger span(mm) | R3X | 8600 | 8600 | 8600 | 8600 | 8600 | 8600 |
