SUMMARY
Tus HOWO Heavy Wrecker Tow Recovery Truck is a robust and versatile vehicle designed for towing and recovering breakdown cars, tsheb, buses, and trailers on the road. With a rising number of private vehicles, this recovery truck is extensively used by governmental organizations and towing companies. This heavy-duty recovery truck is available with optional brands such as HOWO, Dongfeng, Isuzu, JAC, JMC, Cov duab, Shacman, thiab ntau dua. It features high-quality spare parts, including Italy-brand multi-way valves and balance valves, German Roxroth technology hydraulic cylinders and joints, imported sealing elements, and reinforced checked plates.
Tus recovery truck is available in various capacity ranges, from 3 tons to 50 tons yog li tons, ensuring it can handle a wide range of recovery tasks. It also offers the option of a fifth-wheel attachment for towing trailers. The truck’s specifications are optimized for effective recovery operations while maintaining the safety of both the towing vehicle and the vehicle being recovered.
Tus Wrecker Tsheb Tsheb is an indispensable asset for efficient and reliable recovery operations, offering exceptional lifting capacity, advanced hydraulic systems, and a rugged chassis design to handle diverse recovery scenarios with ease and safety.
Nta
- Chassis:
- Equipped with the HW76 standard cabin, available for right or left-hand drive.
- Air-conditioned cabin accommodating 2 to 3 persons.
- Curb Weight: 13070 kg.
- Front axle load: 7000 kg * 2.
- Rear axle load: 18000 kg * 2.
- Max. Overall Weight: 31000 kg.
- Overall Dimensions: 11430 lub hli (Length) x 2500 lub hli (Width) x 3270 lub hli (Height).
- Wheelbase: 1800 + 4600 + 1350 lub hli.
- Max. Speed: 105 km/h.
- Max. Grade-ability: 30%.
- Min. Turning Diameter: 22.6 m.
- Engine: WD615.47 with 371 HP and 9726 mL displacement.
- Transmission: HW19710, 10 forwards & 2 reverses.
- Wrecker Equipment:
- Max. Towing Weight: 43000 kg.
- Lifting System: Max. Lifting Weight of 25000 kg.
- Max. Lifting Weight under all extensions: 8300 kg.
- Corbeling Arm:
- Effective Length: 3650 lub hli.
- Extend-retract: 1750 lub hli.
- Slope Angle: 7°.
- Folding angle under no load: -7° to 92°.
- Folding angle under load: -7° to 16°.
- Max. Ground Distance: Less than 900 lub hli.
- Landing Strength: 80 * 2 KN.
- Hydraulic Hose: Tianhe, Guangdong Province.
- Hydraulic Joint: German technology and exported sealing rings.
- Hydraulic Lock: Jiangyin Mingcheng Hydraulic and Mechanical Co., Ltd.
- Swivel Joint: Yangzhou Zhongmei Pressure Parts Co., Ltd.
- Compartment plate: Formed using Germany 3P2A 1000T punching machine for exceptional quality and strength.
SPECIFICATIONS
CHASSIS | |||||
Cabin | HW76 standard cabin, Right or left-hand drive, with air conditioner, allowed for 2~3 persons | ||||
No load(kg) | Curb Weight | 13070 | |||
Front axle | 7000*2 | ||||
Rear axle | 18000*2 | ||||
Full load | Max. Overall Weight | 31000 | |||
Overall Dimensions(lub hli) | Length | 11430 | |||
Width | 2500 | ||||
Height | 3270 | ||||
Wheelbase(lub hli) | 1800+4600+1350 | ||||
Track(lub hli) | 2022/1830 | ||||
F/R Suspension(lub hli) | 1500/2200 | ||||
A/D Angle(°) | 16/18 | ||||
Driving Model | 8X4 | ||||
Tyre | 12R22.5 | ||||
Max. Speed(km/h) | 105 | ||||
Max. Grade-ability(%) | 30 | ||||
Min. Turning Diameter(m) | 22.6 | ||||
Min. Ground clearance(lub hli) | 310 | ||||
Engine | Model | WD615.47 | |||
Lub tsev nyob hoom(HP) | 371 | ||||
Displacement(mL) | 9726 | ||||
Transmission | HW19710,10 forwards&2 reverses | ||||
WRECKER EQUIPMENT | |||||
Max. Towing Weight(kg) | 43000 | ||||
Lifting System | Max. Lifting Weight(kg) | 25000 | |||
Max. Lifting Weight under all extensions (kg) | 8300 | ||||
Effective Length of Corbeling Arm(lub hli) | 3650 | ||||
Extend-retract of Corbeling Arm(lub hli) | 1750 | ||||
Slope Angle of Corbeling Arm(°) | 7 | ||||
The folding angle under no load(°) | -7~92 | ||||
Folding angle under load(°) | -7~16 | ||||
Max. Ground Distance(lub hli) | ≮900 | ||||
Landing Strength(KN) | 80*2 | ||||
Hydraulic Hose | Tianhe, Guangdong Province | ||||
Hydraulic Joint | German technology and exported Sealing rings | ||||
Hydraulic Lock | Jiangyin Mingcheng Hydraulic and Mechanical Co., Ltd. | ||||
Swivel Joint | Yangzhou Zhongmei Pressure Parts Co., Ltd. | ||||
Compartment plate | One-step Modeling by Germany 3P2A 1000T punching machine |
