Luv
Tus ISUZU 28m Insulated thoob Truck, produced by CSCTRUCK Tow Crane, is a versatile and efficient vehicle designed for tasks requiring elevated access. This truck features a maximum working height of 28 meters, making it suitable for a variety of applications such as maintenance of street lights, electrical line servicing, and installation of high-rise signage. Built on the robust ISUZU chassis, it offers reliability and durability synonymous with the ISUZU brand.
The truck operates on a 4×2 drive type, ensuring adequate traction and stability on urban and semi-urban roads. Powered by an ISUZU engine with 132 horsepower, it combines sufficient power with efficiency, making it a dependable choice for operators. The vehicle can achieve a maximum driving speed of 105 km/h, facilitating quick travel between job sites.
One of the key features of this bucket truck is its insulated bucket, designed to provide safety for operators working on electrical installations. The bucket has a loading rating of up to 200 kilograms, accommodating both the worker and necessary tools comfortably.
Zuag qhia tag nrho, tus ISUZU 28m Insulated Bucket Truck from CSCTRUCK Tow Crane stands out for its high working height, robust ISUZU engineering, and safety features. It is tailored to meet the demands of professionals in various maintenance and installation roles, ensuring efficiency and safety in elevated work environments.
Nta
1. 28m Max Working Height: Tus ISUZU 28m insulated bucket truck produced by CSCTRUCK Tow Crane offers a maximum working height of 28 meters, making it ideal for high-reach tasks such as maintenance of overhead power lines, tree trimming, and other elevated work.
2. ISUZU Chassis and Engine: Built on a robust ISUZU chassis, this bucket truck is powered by a reliable ISUZU engine brand, ensuring durability and performance. The engine provides 132 horsepower, contributing to the vehicle’s efficient operation and longevity.
3. 4×2 Drive Type: Featuring a 4×2 drive type, this bucket truck is designed for optimal maneuverability and stability on paved and slightly uneven surfaces. This drive configuration is well-suited for urban and suburban environments where high reach and mobility are essential.
4. Max Driving Speed of 105 km/h: The truck can achieve a maximum driving speed of 105 km/h, allowing for timely arrival at job sites. This speed capability ensures that the vehicle can keep pace with highway traffic, reducing travel time between locations.
5. ≤200kg Bucket Rating Loading: The bucket has a maximum loading capacity of 200 kilograms, accommodating personnel and equipment necessary for various tasks. This rating ensures safety and efficiency during operations at height, complying with industry standards for bucket trucks.
Kev qhia tshwj xeeb
ISUZU 28m Insulated Bucket Truck |
|
| Overall dimensions(LxWxH) | 8,060×2,480×3,200mm |
| Maximum Height | 28 meters |
| Maximum operation radius | 10.6 meters |
| Gross vehicle weight | 8,280 kg |
| Mass in working order | 8,150 kg |
| Wheelbase | 3,815 lub hli |
| F/R track base | 1,640/1,655lub hli |
| Approach/departure angle | 23/10° |
| Cabin | ISUZU Right/Left Hand Driving, with A/C. |
| Engine | Diesel Engine 132Hp, 4 Stroke, 4 Cylinder in line, Turbocharged, Inter cooling |
| Displacement/ HP | 2,999 Liter/132HP |
| Max speed | 105 km/h |
| Tire specification | 7.50R16LT 14PR |
| Traction system | 4×2 |
| Number of axles | 2 |
| Equipment | 1. Max operation height:26m 2. Max operation radius≤10.6m, 3. Max working platform height≤26m, 4. Working platform rating loading≤200kg, 5. Working platform rating allowable passengers=2, 6. 360°turning(left or right) 7. The cage be operated both in the air and on the earth |
