Ringkes
Fitur
Spesifikasi
| Informasi dhasar | |
| Formulir Drive | 4X2 |
| Wheelbase | 3300mm |
| Vehicle body size | 5.995×2.3×2.345 meters |
| Gunggunge Jawaban | 4.495 Ton |
| Bobot kendharaan | 3.795 Ton |
| Kacepetan maksimal | 110KM / H |
| Trek ngarep / mburi mburi | Ngarep:1680mm; mburi:1495mm |
| Ngarep overhang ngarep / mburi overhang | 1.125/1.57 meter |
| Parameter mesin | |
| Model Mesin | Foton Cummins ISF2.8s5129T |
| Pamindahan | 2.78L |
| Tenaga maksimal | 129 Tenaga jaran |
| Daya output maksimal | 96kw |
| Jinis bahan bakar | Diesel |
| Standar emisi | Euro V |
| Dipasang paramèter peralatan | |
| Merek Peralatan Dipasang | Chusheng brand |
| Kapasitas lift | 505kg |
| Others | Original factory air conditioner, electric windows and doors, remote key, ABS+EBD, car Bluetooth, reversing image, heated rearview mirrors and other multi-functions; Mounted equipment:The mounted equipment adopts imported parts, 3P2A folding stamping flat plate, one towing two type, bilateral linkage operation device. The plate can bear 3.5 Ton. 40KN hydraulic winch (25-meter steel wire rope), imported multi-way valve and balance valve (HYDAC, Italia). The plate is 4.2+1.2 meters long and 2.3 meters wide. It can slide and stretch and contact the ground at a small angle. The two sections of the rear lifting arm can be telescopically lifted. The effective length is 1.5 meter. It can lift 2 tons and tow 4 Ton. It is equipped with 1 toolbox, 1 hand washing box, a pair of L-shaped tire holders, a pair of fork seats, 2 auxiliary trolleys, straps, chain hooks, etc. according to the factory standard configuration. |
| Parameter transmisi | |
| Model Transmisi | WLY5G40 of Wanliyang |
| Jumlah Gear | 5 gaman |
| Jumlah gear mbalikke | 1 |
| Parameters Chassis | |
| Brand Chassis | Hyundai Commercial Vehicle |
| Chassis vehicle series | Shine H3 |
| Model Cassis | CHM1043GDC33V |
| Rear axle description | 4-ton Dongfeng Dana axle |
| Jumlah godhong Springs | 4/5+3, 7/7+4, 6/6+4, 8/8+4, 3/9+7 |
| Ban | |
| Jumlah ban | 6 |
| Spesifikasi Tirus | 7.00R16 steel-belted tire |
