ფოტოები 4.5 Tons Side Lifter Crane is a robust and versatile piece of heavy machinery designed for efficient lifting and transportation of heavy loads. Here are its key features:
- Engine and Performance: Powered by a 2.8L, 4-cylinder diesel engine, the crane delivers a maximum torque of 172 Nm at 2,200 rpm. This ensures it has the necessary power to handle heavy lifting tasks.
- Transmission: It comes with a 5-speed manual transmission, providing the operator with control over the crane’s movement and lifting operations.
- Dimensions and Capacity: With a length of 6,010 მმ, width of 1,990 მმ, and height of 2,280 მმ, the crane is designed for maneuverability and stability. It has a ground clearance that allows it to navigate various terrains, though the exact measurement is not specified.
- Safety and Security: The crane is equipped with essential safety features such as Anti-lock Brake System (ABS) and Electronic Brake Distribution, ensuring safe operation. It also includes an immobilizer and security alarm for added security.
- Comfort and Convenience: The cab is equipped with air-conditioning for operator comfort, and it features a push-start button for convenience. The entertainment system includes an AM/FM radio with CD player and MP3 connectivity.
- Lifting Specifications: As a side lifter crane, it is designed to lift and move loads laterally. While specific lifting height and radius are not detailed in the provided information, such cranes are typically engineered for high lifting capacities and reach.
- Fuel Efficiency: The crane runs on diesel and has a fuel capacity of 70.0 ლ, though the combined fuel consumption is not specified.
- Construction and Design: The crane is built with durability in mind, featuring a robust construction that can withstand the rigors of heavy lifting and transportation.
- Operational Features: It offers a 360° rotation for versatile lifting angles and a straight crane specification that allows for efficient use of space during lifting operations.
The ფოტოები 4.5 Tons Side Lifter Crane is an ideal choice for construction sites, warehouses, and other industrial settings where heavy lifting and side loading are required. Its combination of power, უსაფრთხოების მახასიათებლები, and operational capabilities make it a reliable asset for heavy-duty lifting tasks.
სპეციფიკაციები
| ძირითადი ინფორმაცია | |
| Drive Type | 4X2 |
| ბორბლიანი ბაზა | 2700მმ |
| ტიპი | Truck-mounted Crane |
| Vehicle Dimensions | 5 × 2.098 × 2.65 მეტრი |
| Gross Vehicle Mass | 4.495 ტონა |
| Rated Mass | 1.8 ტონა |
| Front Overhang/Rear Overhang | 1.115 / 1.185 მეტრი |
| Front Tread | 1490მმ |
| Rear Tread | 1550მმ |
| ძრავის პარამეტრები | |
| Engine Model | Quanchai Q23 – 132E60 |
| გადაადგილება | 2.3ლ |
| Maximum Output Power | 97კვტ |
| Maximum Horsepower | 132hp |
| ემისიის სტანდარტი | China VI |
| Fuel Type | დიზელი |
| Rated Rotational Speed | 3000rpm |
| ძრავის ბრენდი | Quanchai |
| Cargo Box Parameters | |
| Cargo Box Length | 2.6 მეტრი |
| Cargo Box Width | 1.9 მეტრი |
| Cargo Box Height | 0.4 მეტრი |
| Mounted Equipment Parameters | |
| Mounted Equipment Brand | Shenbai Heavy Industry Brand |
| Crane Model | SQS25 |
| Lifting Capacity | 1 ton |
| Self-weight of Crane | 0.57 ton |
| Cab Parameters | |
| კაბინა | Single Row |
| გადაცემის პარამეტრები | |
| Transmission Model | 5-speed Transmission |
| Number of Gears | 5-speed |
| შასის პარამეტრები | |
| Chassis Brand | Foton Aoling |
| Chassis Series | Aoling M Card |
| Chassis Model | BJ1044V9JB4 – AA1 |
| Number of Leaf Springs | 3 / 5 + 3 |
| Frame Size | 140(4 + 5)მმ |
| Gear Ratio | 4.875 |
| საბურავები | |
| Number of Tires | 4 |
| Tire Specification | 6.50R16LT 10PR / 235 / 75R17.5 14PR |
| Control Configuration | |
| ABS Anti-lock | Standard Equipment |
| Clutch Assist | Standard Equipment |
| Power Steering | Standard Equipment |
| Internal Configuration | |
| Reverse Radar | Optional Equipment |
| Remote Key | Standard Equipment |
| Electronic Central Locking | Standard Equipment |
| Multifunctional Steering Wheel | Standard Equipment |
| Air Conditioning Adjustment Form | Manual |
| Power Windows | Standard Equipment |
| Power Outlet | Standard Equipment |
| Multimedia Configuration | |
| External Audio Source Interface (AUX/USB/iPod, etc.) | Standard Equipment |
| რადიო | Standard Equipment |
| Lighting Configuration | |
| Front Fog Lights | Optional Equipment |
| Headlight Height Adjustment | Standard Equipment |
