ម៉ុកសុខ 4 Ton Tilt Tray Self Loader Tow Truck with Crane

SUMMARY

នេះ ម៉ុកសុខ 4 Ton Tilt Tray Self Loader Tow Truck with Crane is a versatile and powerful road rescue vehicle designed to handle various towing and recovery tasks. With a combination of a flatbed tow truck and a 3-ton crane, this vehicle offers efficient and reliable towing, lifting, and recovery capabilities. Built on a HOWO chassis, this tow truck is engineered to deliver optimal performance, making it an indispensable asset for road rescue operations.

The HOWO Self Loader ឡានដឹកទំនិញដែលមានរថយន្តស្ទូច offers a comprehensive solution for road rescue operations. Combining a versatile flatbed tow truck with a powerful crane, this vehicle demonstrates exceptional performance, reliability, and adaptability in various towing, lifting, and recovery scenarios. Its engineering excellence, towing capacity, and versatile features make it a crucial asset for effective road rescue missions.

លក្ខណៈពិសេស

General Specifications:

• Truck Name: Tilt Tray Wrecker Tow Truck
• Drive Type: 4*2
• Gross Vehicle Weight: 8280 ខេក
• Curb Weight: 6150 ខេក
• Overall Dimensions (LWH): 7430×2300×2470 mm

Engine:

• យីហោម៉ាស៊ីន: Yun Nei
• Fuel Type: Diesel
• Power: 85kw/116HP
• Emission Standard: Euro III
• Displacement: 3856 ml
• Engine Type: 4 cylinders in line, water cooling, turbocharged diesel engine, inter-cooling

Chassis:

• Chassis Brand: ម៉ុកសុខ
• Cabin: Flat roof, one row, with A/C
• Tire No.: 6+1
• Tire Specification: 8.25R16 Steel tire
• Wheelbase: 3800 មមលក់ម្យ៉ាង
• Axle No.: 2
• Gear Box: 6-speed forward with 1 reverse, manual
• Brake: Air brake
• Steering Wheel: Left-hand drive with power-assisted
• Radiator: Suitable for tropical climate

Towing and Lifting:

• Crane: Telescope straight boom crane
• Max Lifting Weight of Crane: 4000 ខេក
• Max Lifting Height of Crane: 9.5 m
• Max Working Radius of Crane: 7.6 m
• Towing Capacity: 2000 ខេក

Flatbed:

• Flatbed Size: 5600×2300 មមលក់ម្យ៉ាង
• Flatbed Material: Checker plate or punch plate

Versatile Capabilities:

• This HOWO tow truck combines the functionality of a flatbed tow truck with a powerful 3-ton crane, enabling efficient towing, lifting, and recovery operations.
• The telescopic straight boom crane with a maximum lifting weight of 4000 kg and a height of 9.5 m provides substantial lifting power for a variety of scenarios.
• The flatbed’s spacious size of 5600×2300 mm and its durable material options, such as checker plate or punch plate, ensure secure and stable transport of various vehicles.

Reliable Performance:

• The vehicle’s diesel engine, compliant with Euro III emission standards, delivers a robust power output of 85kw/116HP, suitable for demanding towing tasks.
• Equipped with air brakes and a suitable radiator for tropical climates, this tow truck ensures reliable stopping power and efficient cooling in varying conditions.





Items	Descriptions	Specifications and Types
General	Truck Name	Tilt Tray Wrecker tow truck
	Drive Type	4*2
	Gross Vehicle Weight(ខេក)	8280
	Curb Weight (ខេក)	6150
	Overall Dimensions L*W*H(មមលក់ម្យ៉ាង)	7430×2300×2470
Engine	យីហោម៉ាស៊ីន	Yun Nei
	Fuel Type	Diesel
	Power	85kw/116HP
	Emission Standard	Euro III
	Displacement(ml)	3856
	Engine Type	4 cylinders in line, water cooling, turbocharged diesel engine,inter-cooling
Chassis	Chassis Brand	ម៉ុកសុខ
	Cabin	Flat roof, one row, with A/C
	Tire No.	6+1
	Tire Specification	8.25R16 Steel tire
	Wheelbase (មមលក់ម្យ៉ាង) ;	3800
	Axle No.	2
	Gear Box	6-speed forward with 1 reverse, manual
	Brake	Air brake
	Steering Wheel	Left-hand drive with power-assisted
	Radiator	Suitable for tropical climate
Towing and lifting	Crane	telescope straight boom crane
	Max lifting weight of crane(ខេក)	4000ខេក
	Max lifting height of crane(m)	9.5
	Max working radius of crane(m)	7.6
	Towing capacity(ខេក)	2000
Flatbed	Flatbed Size	5600×2300
	Flatbed Material	Checker plate or punch plate
