Kuerz:
The SINOTRUK 8 Ton Wrecker Tow Truck is a powerful and versatile vehicle designed to handle towing and recovery tasks with utmost efficiency. With a robust engine, hydraulic capabilities, and specialized devices, it’s ready to tackle a wide range of roadside challenges. Whether it’s recovering stranded vehicles or towing those in need, this wrecker tow truck is built to get the job done effectively and reliably.
This tow truck is a reliable and powerful solution for all your towing and recovery needs. Its robust design, powerful engine, and specialized equipment make it a versatile and essential addition to any fleet.
FONTassementer:
- Cabin: The spacious and comfortable cabin features a hydraulically tiltable design, allowing the driver to operate with ease. It includes air conditioning and a single bed for added comfort during long shifts.
- Vehicle Main Dimensions: This truck boasts substantial dimensions, measuring 9220 mm in length, 2500 mm in width, and 3320 mm in height. With a wheelbase of 5600 mm and front/rear wheel tracks of 2022/1830 mm, it offers stability and maneuverability.
- Engegkeeten no: Powered by a SINOTRUK WD615.87 engine, this wrecker truck delivers a robust 290 HP. Its 6-cylinder, water-cooled, turbocharged, and intercooled design ensures reliable performance.
- Eventéieren: Equipped with an HW15710 gearbox, offering 10 forward and 2 reverse gears for optimal control during operation.
- Stréckt: The ZF8098 power steering with hydraulic assistance provides precise and responsive control of the vehicle.
- KLEMch: A reinforced diaphragm clutch with a diameter of 430 mm ensures dependable power transmission.
- Fuel Tank: The 300-liter fuel tank offers sufficient capacity for extended operations, reducing refueling frequency.
- Tire: It features 12R22.5 tubeless tires, including a spare tire, ensuring traction and reliability on the road.
- Specialized Device (Boom Structure):
- Lifting Capabilities: The wrecker truck can handle a maximum lifting weight of 5745 KG. It can lift up to 8000 kg in its original position and 4000 kg at full extension.
- Towing Capacity: With a rated towing weight of 19000 KG, this truck can efficiently tow a wide range of vehicles.
- Boom Length: The effective length of the boom is 3560 Meter sinn, and it can extend up to 1700 Meter sinn.
- Flexibility: The boom has a folding angle of up to 90 Grad, allowing for versatile positioning during recovery operations.
- Underlift Structure: The underlift structure supports a maximum rated hanging weight of 8000 KG. It provides the ability to tow and recover vehicles efficiently, with a hook height of 5690 mm above the ground.
SPECIFICATIONS:
| Gemengen | Spezifikatioune |
|---|---|
| Cabin | |
| Driving Type | 4×2 |
| Left-Hand Drive (LHD) | Yes |
| Cabl äregaang | HW76 with A/C, one bed, 70° hydraulically tiltable |
| to the front | |
| Vehicle Main Dimensions | |
| Am Ganzen Dimensiounen (LxWxH) | 9220 x 2500 x 3320 mm |
| Wheelbase (mm) | 5600 |
| Wheel Track (Front/Rear) | 2022/1830 |
| Weight in KGS | |
| Tarre Gewiicht | 16600 KG |
| Front Axle Loading Capacity | 7000 KG |
| Rear Axle Loading Capacity | 16000 KG |
| Max. Driving Speed (km/h) | 90 |
| Engegkeeten no | |
| Brand | SINOTRUK |
| Model | WD615.87 |
| Tipps | 4-stroke direct injection, 6-cylinder in-line with |
| water cooling, turbo-charging, and inter-cooling | |
| Horsepower (HP) | 290 HP |
| Emissiounsond Standard | Euro 2, Euro 3, Euro 4, Euro 5 |
| Gearbox | |
| Model | HW15710 |
| Eventéieren | 10-speed forward, 2 reverse gears |
| Stréckt | |
| Tipps | ZF8098 power steering |
| Power Assistance | Hydraulic steering with power assistance |
| KLEMch | |
| Tipps | Reinforced diaphragm clutch |
| Entersheemer | 430 mm |
| Fuel Tank (L) | 300 L |
| Tire | |
| Tipps | 12R22.5 tubeless tires |
| Quantity | 7 pieces (including one spare tire) |
| Specialized Device | |
| Boom Structure | |
| Rated Lifting Weight (KG) | 5745 |
| Max. Lifting Weight of | 8000 KG |
| Original Place (KG) | |
| Max. Lifting Weight of | 4000 KG |
| Full Extension Boom (KG) | |
| Rated Towing Weight (KG) | 19000 KG |
| Effective Length of Boom | 3560 m |
| Extension Traveling of Boom | 1700 m |
| Folding Angle of Boom (°) | 90 |
| Underlift Structure | |
| Max. Rated Hanging Weight | 8000 KG |
| Height from the Hook to the | 5690 mm |
| Ground (mm) |
