Genlyon C500 450Horsepower 8X4 31Ton Truck Mounted Crane Vehicle

SUMMARY

• It is equipped with a robust 450 – horsepower engine that provides the necessary muscle to perform various tasks. The high horsepower enables the vehicle to carry out operations with efficiency, whether it’s transporting heavy loads or operating the mounted crane. The 8X4 drive configuration offers excellent traction and stability, making it suitable for diverse terrains such as rough construction sites and long – haul routes.
• With a maximum load capacity of 31 တန်, the truck can handle a substantial amount of cargo. The truck – mounted crane further enhances its versatility, allowing it to lift and move heavy objects on – site without the need for additional lifting equipment.

• The crane on the vehicle is a key component. It is designed to handle loads up to 31 တန်, enabling it to lift and place a wide range of heavy items. In construction sites, it can be used to lift building materials like large steel beams, pre – cast concrete elements, and heavy machinery.
• The crane provides precise control over the movement of the load, which is crucial in construction projects where accurate placement of materials is essential for proper building structures.

• ဆောက်လုပ်ရေးလုပ်ငန်းမှာ, this vehicle is an invaluable asset. It can be used for transporting construction materials to and from the site and also for directly placing them in the required positions during the building process. It is also suitable for infrastructure projects like road and bridge construction, where heavy materials need to be lifted and installed.
• စက်မှုဇုန်များတွင်, it can be used for handling large and heavy equipment during maintenance, installation, or relocation. It can also be employed in warehouses for loading and unloading bulky items from trucks or for moving them around within the storage area.

• The cab of the truck is likely designed with the operator’s comfort in mind. It may have ergonomic seating to reduce fatigue during long working hours. The controls for both driving the truck and operating the crane are probably designed to be user – friendly.
• For the crane operator, there may be a well – laid – out control panel with clear instructions and indicators, enabling precise control of the crane’s movements. The overall design aims to provide a safe and efficient working environment for those operating the vehicle.

အင်္ဂါရပ်များ

Power and Drivetrain

• Engine Power
  • ဟိ 450 – horsepower engine is a significant feature of this vehicle. It provides substantial power, allowing the truck to handle its 31 – ton load capacity with ease. This high – powered engine is essential for both driving the vehicle on various terrains and operating the mounted crane effectively. Whether it’s climbing steep inclines on construction sites or traveling long distances on highways during transportation, the engine’s output ensures smooth and efficient performance.
• 8X4 Drive Configuration
  • The 8X4 drive system offers multiple advantages. It provides excellent traction, which is crucial for a vehicle of this size and load – carrying capacity. This configuration distributes the vehicle’s weight more evenly across the axles, enhancing stability during movement. It is well – adapted to different terrains, from rough construction sites to paved roads, reducing the risk of wheel slippage. ထို့ အပြင်, it contributes to better handling when making turns, especially in tight spaces on construction sites or during loading and unloading operations.

Load Capacity and Crane Features

• 31 – Ton Load Capacity
  • With a load capacity of 31 တန်, the Genlyon C500 can transport a large volume of heavy materials. This includes construction materials such as steel girders, pre – cast concrete elements, and heavy machinery parts. In industrial applications, it can carry bulky raw materials or finished products. The high load capacity makes it a valuable asset in industries that require the transportation of heavy items.
• Crane Capabilities
  • The truck – mounted crane is a central feature. It is designed to work in harmony with the truck’s load – carrying capacity, having a lifting capacity of up to 31 တန်. The crane is likely equipped with a sophisticated hydraulic system that enables smooth and precise lifting operations. It offers a good reach and a wide range of motion, allowing it to access different areas on a construction site or within an industrial facility. The crane provides precise control over the load’s movement, which is crucial for tasks such as erecting building structures in construction and handling equipment in industrial settings.

Construction and Industrial Applications

• Versatility in Construction
  • In construction projects, this vehicle is highly versatile. It can be used for transporting construction materials from suppliers to the building site. Once on – site, the crane can be used to unload the materials directly and place them in the exact location required, reducing the need for additional handling equipment. It can be involved in various construction tasks, such as erecting scaffolding, lifting and placing roofing materials, and installing large – scale structural components.
• Industrial Applications
  • စက်မှုဇုန်များတွင်, the Genlyon C500 truck – mounted crane serves multiple purposes. It can be used for loading and unloading heavy equipment during installation, maintenance, or relocation. ဥပမာအားဖြင့်, in a manufacturing plant, it can move large – scale machinery for repair or repositioning. In warehouses, it can load and unload bulky items from trucks and place them in the appropriate storage locations, optimizing the use of storage space.

Safety and Operator Comfort

• ဘေးကင်းရေးအင်္ဂါရပ်များ
  • The vehicle is likely equipped with a range of safety features. Overload protection systems for both the truck and the crane prevent overloading, safeguarding the vehicle’s structural integrity and ensuring safe operation. Stability – enhancing mechanisms ensure that the truck remains stable during crane operations, especially when lifting heavy loads at extended reaches. Safety locks on the crane prevent accidental movement of the boom or load, and there may be warning systems to alert the operator of any abnormal operating conditions.
• Operator Comfort
  • The cab of the truck is designed with the operator’s comfort in mind. It may have ergonomic seating with adjustable features to support different body types and reduce fatigue during long working hours. The controls for driving the truck are conveniently placed and easy to operate. For the crane operator, there is likely a well – designed control panel with clear labels and indicators. The panel provides intuitive control over the crane’s movements, and the operator has a good view of the lifting area to ensure accurate and safe operations. ထို့ အပြင်, the cab may be insulated from noise and vibration, creating a more pleasant working environment.

SPECIFICATIONS

အခြေခံအချက်အလက်
Drive form	8X4
ဘီးတပ်	2025 + 4375 + 1400မီလီမီတာ
Type	ထရပ်ကား – mounted crane vehicle
Vehicle dimensions	11.98 × 2.55 × 3.89 မီတာ
Total mass	31 တန်
Rated mass	11.43 တန်
Front overhang / Rear overhang	1.435 / 3.745 မီတာ
အင်ဂျင်ပါရာမီတာများ
အင်ဂျင်မော်ဒယ်	SAIC – FPT F3GCE611A*L
Displacement	11.12L
အများဆုံးထွက်ရှိပါဝါ	327kW
Maximum horsepower	450 မြင်းကောင်ရေ
Emission standard	National V
Fuel type	Diesel
Rated speed	1900rpm
Engine brand	SAIC – FPT
Maximum torque	2100N·m
Maximum torque speed	1100 – 1500rpm
Mounting Parameters
Vehicle announcement	CQ5316JSQHTVG466
Mounting brand	SAIC Hongyan
Crane model	SQS400
Lifting weight	16 တန်
Crane self – ကိုယ်အလေးချိန်	6.455 တန်
Cab Parameters
Cab	Flat – top
Transmission Parameters
Transmission model	Fast 12JSD220TA
Number of gears	12 – speed
Chassis Parameters
Chassis brand	SAIC Hongyan
Chassis series	Genlyon
ကိုယ်ထည်မော်ဒယ်	CQ1316HTVG39 – 486
Rear axle description	16T Hande axle
Number of spring leaves	3/3/4, 3/3/6, 9/9/12, 5/5/6, 3/3/12
Speed ratio	5.262
Tires
Number of tires	12
Tire specification	11.00R20
