SUMMARY
FEATURES
Power and Drivetrain
Towing Capacity and Towing Features
Application and Utility
Safety and Operator Comfort
SPECIFICATIONS
| Basic Information | |
| Drive form | 4X2 |
| Wheelbase | 3280mm |
| Type | One – tow – two wrecker |
| Vehicle dimensions | 5.995 × 2.3 × 2.4m |
| Gross mass | 4.495 tons |
| Vehicle mass | 3.8 tons |
| Maximum speed | 89km/h |
| Front wheel track / Rear wheel track | Front:1605mm; Rear:1595mm |
| Front overhang / Rear overhang | 1.175 / 1.54m |
| Engine Parameters | |
| Engine model | Weichai WP2.3NQ130E61 |
| Displacement | 2.29L |
| Maximum horsepower | 130 horsepower |
| Maximum output power | 96kW |
| Fuel type | Diesel |
| Emission standard | National VI |
| Mounting Parameters | |
| Vehicle announcement | HNY5048TQZZ6 |
| Mounting brand | Juchenwang brand |
| Others | Tail – flip, tail – telescopic plate, middle – telescopic plate, full – landing, integrated plate, tow – and – hoist combined, one – tow – one |
| Transmission Parameters | |
| Transmission model | 6 – speed transmission |
| Number of gears | 6 – speed |
| Number of reverse gears | 1 |
| Chassis Parameters | |
| Chassis brand | Sinotruk Howoman |
| Chassis series | Howoman H3 |
| Chassis model | ZZ1048G17FB5 |
| Number of spring leaves | 3/5 + 3 |
| Tires | |
| Number of tires | 6 |
| Tire specification | 7.00R16LT 8PR, 7.50R16LT 6PR, 8.25R16LT 6PR |
