Dongfeng 13.5 Ton Telescopic Aerial Lift Truck

Dongfenga 13.5 Ton Telescopic Aerial Lift Truck

Dongfenga 13.5 Ton Telescopic Aerial Lift Truck

Drive Form	4×2
Rozstaw osi	3800mm
Body Dimensions	8.26×2.51×3.87M
Total Mass	13.49 Mnóstwo
Front Overhang/Rear Overhang	1.43/2.19M
Front Track/Rear Track	Front：1896; Rear：1860mm

Zapytanie o ciężarówkę

Opis
Recenzje (0)

KRÓTKI

The Dongfenga 13.5 Ton Telescopic Aerial Lift Truck is a highly efficient and reliable equipment.

It has a load capacity of 13.5 mnóstwo, enabling it to carry a considerable amount of workers and necessary tools for high-altitude operations. The telescopic boom of this truck is designed to extend and retract smoothly, allowing it to reach different heights precisely. It is widely used in construction sites, power facilities maintenance, and other scenarios where high-altitude work is required. With its stable performance and excellent maneuverability, the Dongfeng 13.5 Ton Telescopic Aerial Lift Truck ensures the safety of operators during the work process and greatly improves the efficiency of high-altitude work tasks.

CECHY

The Dongfenga 13.5 Tona Teleskopowy podnośnik powietrzny has the following features:

First of all, it has a substantial load capacity of 13.5 mnóstwo. This allows it to bear a significant weight of personnel and relevant tools when conducting aerial operations, which is crucial for handling heavy-duty tasks in high-altitude work scenarios.

The telescopic boom of this truck is of high quality and flexibility. It can be extended and retracted with great ease and precision, enabling the truck to reach to the desired heights accurately, whether it’s for cleaning the exterior of high-rise buildings or performing maintenance work on power lines.

Pod względem bezpieczeństwa, it is equipped with advanced safety systems. There is an effective overload protection device to prevent overloading and ensure the safety of operators during the high-altitude work process. The chassis of the truck is sturdy and reliable, providing excellent stability when working at the work site, and it also has good driving performance, enabling it to move flexibly from one work location to another, thus enhancing the efficiency of high-altitude work operations.

SPECYFIKACJA

Podstawowe informacje
Drive Form	4×2
Rozstaw osi	3800mm
Typ	Teleskopowy podnośnik powietrzny
Body Dimensions	8.26×2.51×3.87M
Total Mass	13.49 Mnóstwo
Vehicle Weight	13.295 Mnóstwo
Front Overhang/Rear Overhang	1.43/2.19M
Front Track/Rear Track	Front：1896; Rear：1860mm
Engine Parameters
Model silnika	Dongfeng Cummins B6.2NS6B230
Przemieszczenie	6.2L
Maximum Output Power	169kW
Maximum Horsepower	230 Horsepower
Norma emisji	Narodowy VI
Transmission Parameters
Transmission Model	Fast 8-speed
Number of Gears	8 Gears
Chassis Parameters
Marka podwozia	Dongfeng Commercial Vehicle
Chassis Series	Tianjin VR
Chassis Model	DFH1140B
Number of Leaf Springs	8/10+8
Opony
Number of Tires	6 Pieces
Tire Specification	10.00R20 18PR
