KRÓTKI:
The JAK 40 Ton Recovery Rotator Towing Truck is a heavy-duty wrecker designed to tackle challenging recovery and towing tasks with ease. With powerful capabilities and advanced features, it is the ideal solution for efficiently handling substantial lifting and towing requirements in various situations.
The towing truck is designed to excel in challenging recovery scenarios, offering heavy lifting capabilities, stability, and reliable equipment to handle the toughest towing tasks. It is a dependable choice for professionals in the recovery and towing industry.
CECHY:
- Robust Boom and Outriggers:
- Max Lifting Weight of 30,000 kg ensures the truck can handle heavy loads.
- A Boom Extended Length of 4,500 mm provides extended reach.
- Achieve a Max Lifting Height of 12,300 mm, suitable for various recovery scenarios.
- The inclination Angle can be adjusted from 5° to 60° to accommodate different angles.
- 360° Rotating Angle ensures flexible positioning.
- The 3-stage boom offers versatility in lifting operations.
- Outstanding Towing Capacity:
- Equipped with high-capacity outriggers with a Rated Lifting Weight of 12,500 kg.
- Offers a Rated Lifting Fully Extended Weight of 4,500 kg for versatile applications.
- The longitudinal Span between the Front Outrigger and Rear Outrigger is 7,350 mm for stability.
- Transverse Span of Front Outriggers: 5,490 mm.
- Transverse Span of Rear Outriggers: 4,387 mm.
- Reliable Recovery Equipment:
- The rotator truck features a high-quality hydraulic system for dependable performance.
- A single-level telescopic lifting arm simplifies the operation and enhances precision.
- Two powerful hydraulic winches (15 tons each) ensure an efficient and safe recovery.
- Comes with essential tools, including a tool case, for added convenience.
- Two outriggers offer additional stability during lifting and towing operations.
- User-Friendly Operation:
- Manual operation device for precise control and adjustments.
- Two floodlights enhance visibility in low-light or nighttime recovery tasks.
- An alarm lamp for added safety during operation.
- Basic accessories ensure a well-equipped and versatile wrecker.
SPECYFIKACJE:
| Wrecker Structure Parameters | |
|---|---|
| Boom | |
| Maksymalny ciężar podnoszenia | 30000 kg |
| Boom Extended Length | 4500 mm |
| Max Lifting Height | 12300 mm |
| Inclination Angle | 5°-60° |
| Rotating Angle | 360° |
| Number of Stages | 3 Stages |
| Outriggers | |
| Rated Lifting Weight | 12500 kg |
| Rated Lifting Fully Extended Weight | 4500 kg |
| Longitudinal Span between Front Outrigger and Rear Outrigger | 7350 mm |
| Transverse Span of Front Outriggers | 5490 mm |
| Transverse Span of Rear Outriggers | 4387 mm |
| Rated Towing Weight | 35000 kg |
| Length of Cable Wire | 25 M |
