KRÓTKI:
The JAK 50 Ton Rotator Tow Truck is a robust and powerful heavy-duty recovery vehicle designed to tackle challenging towing and recovery tasks. With a sturdy chassis and a high-capacity winching system, this truck offers exceptional performance in the world of recovery and towing. Ten rotator tow truck is built to deliver impressive towing and recovery capabilities, making it a reliable and efficient choice for demanding situations.
CECHY:
- Chassis Description:
- Taksówka: Features a single-row non-longhead cab with the ability to turn over for easier access and convenience.
- Kolor: Multiple color options are available to suit your preference.
- Allowable Person in Cab: Can accommodate 2 Do 3 persons comfortably.
- Rozstaw osi: Offers a wheelbase of 1300+4500+1350 mm for stability.
- Number of Axles: Wyposażony w 4 axles for balanced weight distribution.
- Oś przednia: Front axle load capacity of 5000/5000 kg.
- Tylna oś: Rear axle load capacity of 10000/10000 kg.
- Traction System: Utilizes an 8×4 traction system for enhanced power and control.
- Tire Specification: Features sturdy 12.00 tires designed to handle heavy loads.
- Tire Quantity: Wyposażony w 12 tires and an additional spare.
- Engine Description:
- Engine Manufacturer: Powered by Weichai Engines.
- Engine Model: Driven by the robust WD612.47 engine.
- Emission Standard: Complies with Euro 2 emission standards.
- Exhaust: A displacement of 9726 ml.
- Horsepower: Produces an impressive 371 hp.
- Up-parts Description:
- Maks. Under-pulling Capacity: Offers a remarkable under-pulling capacity of 16,000 kg.
- Maks. Under-Hoisting Capacity: Can hoist up to 5,000 kg.
- Rear-Hoisting Length: The rear hoisting length extends to 3,000 mm.
- Platform Size: Features a spacious platform measuring 6,000 X 2,200 mm.
- Platform Max. Pojemność ładowania: Offers a maximum loading capacity of 10,000 kg.
- Winch Number: Wyposażony w 2 powerful winches.
- Rated Traction Force of Each Winch: Each winch provides a high-rated traction force of 50 kN.
- Diameter of Wire Rope: Utilizes robust wire ropes with an 11 mm diameter.
- Length of Wire Rope: Features wire ropes measuring 30 metrów.
- Min. Wire Feed Speed: Offers a minimum wire feed speed of 3.23 m/min.
SPECYFIKACJE:
| Kategoria | Dane techniczne |
|---|---|
| Chassis Description | |
| Taksówka | Single row non-long head cab can turn over |
| Kolor | Optional |
| Allowable Person in Cab | 2/3 |
| Rozstaw osi (mm) | 1300+4500+1350 |
| Number of Axles | 4 |
| Oś przednia | 5000/5000 |
| Tylna oś | 10000/10000 |
| Traction System | 8×4 |
| Tire Specification | 12.00 |
| Tire Quantity | 12+1 |
| Engine Description | |
| Engine Manufacturer | Weichai Engines |
| Engine Model | WD612.47 |
| Emission Standard | Euro 2, Euro 3, Euro 4, Euro 5 |
| Exhaust | 9726 ml |
| Horsepower | 371 hp |
| Up-parts Description | |
| Maks. Under-Pulling Capacity (kg) | 16000 |
| Maks. Under-Hoisting Capacity (kg) | 5000 |
| Rear-Hoisting Length (mm) | 3000 |
| Platform Size (mm) | 6000×2200 |
| Platform Max. Pojemność ładowania (kg) | 10000 |
| Winch Number | 2 |
| Rated Traction Force of Each Winch (kN) | 50 |
| Diameter of Wire Rope (mm) | 11 |
| Length of Wire Rope (mm) | 30 |
| Min. Wire Feed Speed (m/min) | 3.23 |
