Linepe 18 Ton Tow Truck With Crane

Bokhutšoanyane

LIKAROLOANA

• With a towing capacity of 18 tons, this tow truck is capable of handling large and heavy vehicles with ease. It can efficiently tow trucks, buses, construction equipment, and other heavy machinery. The robust construction and high-strength towing mechanism ensure reliable and safe towing operations.

• The integrated crane is a significant feature of this vehicle. It offers additional functionality and versatility, allowing for the lifting and loading of heavy objects. The crane has a certain lifting capacity and reach, enabling it to handle various tasks such as loading damaged vehicles onto the tow truck or moving heavy equipment at construction sites.

• Built to withstand heavy use and demanding conditions, The Linepe 18 Ton Tow Truck With Crane is constructed with high-quality materials. The chassis is sturdy and reinforced to support the weight of the towed loads and the crane’s operations. The body is designed to be durable and resistant to corrosion and damage, ensuring long-term service life.

• Powered by a reliable and powerful engine, this tow truck provides the necessary horsepower and torque to perform its tasks efficiently. The engine is designed for optimal fuel economy, reducing operating costs over time. The transmission system is also engineered for smooth shifting and reliable power transfer.

• Despite its size and towing capacity, The Linepe 18 Ton Tow Truck With Crane is designed to be maneuverable. It has a tight turning radius and responsive steering, allowing it to navigate through narrow streets and congested areas. This makes it suitable for urban and rural environments alike.

• Safety is a top priority, and this tow truck is equipped with a range of safety features. It may include features such as anti-lock brakes, stability control, and reinforced cabs to protect the driver and passengers. The crane is also designed with safety interlocks and overload protection to prevent accidents during lifting operations.

• The controls of the tow truck and crane are designed to be user-friendly and intuitive. The driver can easily operate the towing mechanism and crane controls from the cab, ensuring smooth and efficient operations. The dashboard is well-organized and provides clear visibility of important information.

TLHOKOMELISO

Basic Information
Drive form	4X2
Ho na le Wheelbase	5750mm
Vehicle body size	10.75×2.55×3.8 meters
Total mass	18 tons
Vehicle weight	14.5 tons
Maximum speed	89km / h
Front track/rear track	Front:2008mm; rear:1860mm
Front overhang/rear overhang	1.27/3.37 Metres
Engine Parameters
Engine model	Dongfeng Cummins B6.2NS6B230
Displacement	6.2L
Maximum horsepower	230 Meroo ea pere
Maximum output power	169kW
Fuel type	Diesel
Emission standard	Euro VI
Mounted Equipment Parameters
Mounted equipment brand	Panke brand
Lifting capacity	3370kg
Transmission Parameters
Transmission model	Fast 8JS95TE
Number of gears	8 gears
Number of reverse gears	2
Chassis Parameters
Chassis brand	Foton Auman
Chassis vehicle series	R series
Chassis model	BJ1186VKPHK-1K
Number of leaf springs	10/8+8
Tires
Number of tires	6
Tlhaloso ea mabili	10.00R20 18PR
