CSCTRUCK Tow Crane, a renowned manufacturer in the specialized vehicle industry, has unveiled its latest innovation: தி ISUZU 23m காப்பிடப்பட்ட பக்கெட் டிரக். This cutting-edge vehicle is engineered to meet the diverse needs of utility and maintenance professionals, offering exceptional performance and safety features.
Built on a robust இசுசு chassis with a 4×2 drive type, the new காப்பிடப்பட்ட வாளி டிரக் is powered by a B140 33 engine model, delivering a potent 141 horsepower. The vehicle can reach a maximum driving speed of 90 கிமீ/மணி, ensuring timely arrival at job sites. The standout feature of this truck is its 23-meter maximum working height, providing access to elevated workspaces with ease.
The bucket, designed with insulation for enhanced safety, has a rated weight capacity of 200 kilograms, making it suitable for a wide range of tasks, from electrical line maintenance to tree trimming. This focus on safety is further emphasized by the truck’s ability to maintain stability and control, even under demanding conditions.
The introduction of the ISUZU 23m Insulated Bucket Truck highlights CSCTRUCK Tow Crane‘s commitment to delivering high-quality, reliable vehicles that cater to the evolving needs of their clients. அதன் சக்திவாய்ந்த இயந்திரத்துடன், significant reach, and enhanced safety features, this new model is set to become an invaluable asset for industries requiring elevated work platforms.
அம்சங்கள்
1. High Working Height:
– தி காப்பிடப்பட்ட வாளி டிரக் offers a maximum working height of 23 மீட்டர், making it suitable for tasks that require elevated access such as electrical line maintenance, மரம் வெட்டுதல், and high-reach repairs.
2. Robust ISUZU Chassis:
– Built on a reliable இசுசு chassis, this truck combines durability and performance, ensuring it can withstand the rigors of demanding work environments.
3. Powerful Engine:
– Equipped with a B140 33 engine model that delivers 141 horsepower, the truck has the necessary power to handle various operational needs efficiently.
4. Stable and Efficient Drive Type:
– Featuring a 4×2 drive type, the truck provides stable and controlled driving on most road conditions, ensuring safety and reliability during transit and operation.
5. Ample Bucket Capacity:
– The insulated bucket has a rated weight capacity of 200kg, allowing it to safely carry personnel and tools necessary for the job while offering insulation for added protection when working near electrical hazards.
விவரக்குறிப்பு
ISUZU 23m Insulated Bucket Truck |
|||
| Overall dimensions(LxWxH) | 7,410 x 2,210 x 3,550mm | ||
| Gross vehicle weight | 8,950கிலோ | ||
| வீல்பேஸ் | 3,800 மிமீ | ||
| F/R track base | 1,110/1,990மிமீ | ||
| அணுகுமுறை/புறப்படும் கோணம் | 21/12° | ||
| Cabin | Single Row Cabin, 2 Passenger Allowed, | ||
| இயந்திரம் | Cummins Diesel Engine B140 33, 4 Stroke, 4 Cylinder in line, Turbocharged, Inter cooling | ||
| Displacement/ HP | 3,760CC / 141ஹெச்பி | ||
| Max speed | 90கிமீ/மணி | ||
| Tire specification | 7.60 – 16, 6 Pieces with 1 Spare | ||
| Traction system | 4×2 | ||
| Number of axles | 2 | ||
| Bucket | அதிகபட்சம். work height: 23 மீட்டர் | ||
| அதிகபட்சம். bucket floor height: 22மீட்டர் | |||
| அதிகபட்சம். work radius: 10 மீட்டர் | |||
| மதிப்பிடப்பட்ட சுமை: 200கிலோ | |||
| Dimension(L × w × h): 1,000×650×1,200(மிமீ) | |||
| Boom | Type: 4-section telescopic synchronously | ||
| Rotation angle: 360° | |||
| Elevation angle: -12°~80° | |||
| Outriggers | Type: H | ||
| 4,000×4,000மிமீ | |||
| Major Feature | Outrigger | The computer-controlled system, 1 key to stretch out & balance the level of the truck | |
| Balancing | Automatically Balancing system with Tilting Angle Sensor & level detector | ||
| Getting on & off Lock | A computer control system | ||
| Telescopic Arm Control | Controlling system in the bucket, with manual control | ||
| Platform Control system | LED Screen Display with Button control | ||
| Range Control | Large Angle Sensor to Detect the Arm Length & Rotation Range | ||
| Walkie-Talkie | Included | ||
