Короткий

• With 140 horsepower, this crane is equipped with sufficient power to handle various lifting and transportation tasks. The power output ensures smooth operation, whether it is moving the vehicle to the job site or performing lifting operations.
• The 4X2 drive configuration provides a balance between traction and fuel efficiency. It is suitable for a wide range of terrains, from relatively smooth roads to more challenging surfaces that might be encountered on construction sites or in industrial areas.

• Boasting an 8 – Тонна підйомна ємність, this crane can hoist a significant amount of weight. The four – section boom is a key feature. The multiple sections allow for adjustable reach, providing flexibility in lifting operations. It can be extended or retracted as needed to reach different heights and distances, making it adaptable to diverse job requirements.

• In the construction industry, it can be used for tasks such as lifting building materials like steel beams, concrete blocks, and pre – fabricated components. It is also useful for loading and unloading construction equipment at the site.
• У промислових умовах, it can assist in the movement of heavy machinery parts for maintenance or installation purposes. Додатково, in some cases, it can be employed in infrastructure projects for tasks like lifting and placing components for bridges or other large – scale structures.

• The design of the Huashen T5 crane allows for relatively easy maneuverability. Its 4X2 configuration and overall size make it suitable for navigating through construction sites and industrial yards. It can also be transported to different locations without excessive difficulty, which is important for jobs that require the crane to be moved between multiple sites.

• The operator’s cab is likely designed with comfort in mind. It may have ergonomic seating and controls, allowing the operator to work for extended periods without excessive fatigue. The controls are probably intuitive, enabling the operator to precisely control the crane’s movements, including lifting, swinging, and boom extension or retraction.

Особливості

• Power Output: З 140 – horsepower engine, this crane has a significant amount of power at its disposal. This power is crucial for not only the crane’s lifting operations but also for its mobility on different terrains. It provides the necessary force to hoist heavy loads and to drive the vehicle to and from job sites efficiently.
• 4X2 Drive: The 4X2 drive configuration offers a practical balance. It provides enough traction to handle various surfaces, from paved roads to more uneven ground commonly found at construction sites. This drive type also contributes to fuel efficiency, which is an important factor for long – term operation and cost – effectiveness.

• 8 – Ton Lifting Capacity: The crane’s 8 – ton lifting capacity is a key feature. It allows for the hoisting of a substantial amount of weight, making it suitable for a wide range of applications. Whether it’s lifting building materials, machinery components, or other heavy objects, this capacity ensures that the crane can handle the task effectively.
• Four – Section Boom: The four – section boom is a highly versatile component. Each section can be extended or retracted independently, providing a variable reach. This flexibility in boom length allows the crane to access different heights and distances. Наприклад, it can be adjusted to reach high – rise building floors during construction or to place a load at a specific distance within an industrial site. The boom is also likely constructed with high – strength materials to ensure it can bear the 8 – ton load without structural failure.

• Sturdy Chassis: The crane is built on a chassis that is designed to provide stability during lifting operations. The chassis distributes the load evenly, reducing the risk of tipping. It is engineered to withstand the forces exerted during lifting, swinging, and transportation of the crane.
• Safety Features: To ensure safe operation, this crane is likely equipped with various safety features. A load moment indicator is probably present, which constantly monitors the relationship between the load being lifted, the boom’s angle, and the crane’s position. This device alerts the operator when the crane is approaching its safe working limits, preventing overloading. Антигранний – два – block systems may also be in place to avoid the hoist rope from over – winding, protecting the crane and the load from potential damage.

• Maneuverability on Site: The Huashen T5 crane is designed for relatively easy maneuverability. Its compact size and 4X2 drive make it capable of navigating through narrow passages and tight corners on construction sites or in industrial areas. This allows it to reach the exact location where lifting is required without causing disruption to other ongoing work.
• Transportability: It can be easily transported to different job sites. The overall dimensions and weight of the crane are likely optimized for transportation on standard trailers or trucks. This transportability is essential for contractors who need to move the crane between multiple projects or job locations.

• Comfortable Cab: The operator’s cab is designed with the operator’s comfort in mind. It may feature ergonomic seating, which provides support during long – hour operations. The cab is also likely to have good insulation, protecting the operator from noise and temperature extremes.
• Intuitive Controls: The controls within the cab are designed to be intuitive. The operator can easily manipulate the crane’s functions, such as lifting, swinging, and boom adjustment, Використання важелів, pedals, or other control mechanisms. The controls are likely placed in a logical layout, reducing the learning curve for new operators and enhancing overall efficiency.

Специфікація

Basic Information
Overall machine dimensions	length × width × height
Колісна база	3,650 мм
Total counterweight	12.495 тонн
Maximum traveling speed	80 km/h
Maximum gradeability	30%
Approach angle/departure angle	24/12 ступенів
Engine Parameters
Engine model	Xichai 4DX23 – 140E5
Maximum output power	105 kW
Rated rotational speed	2,800 rpm
Chassis Parameters
Chassis model	EQ1128GLJ2
Підняття потужності
Maximum lifting height – basic boom	25.5 метрів
Length of lifting boom – basic boom	8 метрів
Length of lifting boom – fully extended boom	24.9 метрів
Operation Parameters
Outrigger span	longitudinal × transverse
