BREVE

1. Powerful Chassis and Loading Capacity:
   • It is built on a reliable chassis that can handle a loading capacity of 4.5 Toneladas, ensuring the stability and durability of the vehicle during operation. This allows it to carry not only the bucket lift structure but also necessary tools and equipment for the job.
2. Articulated Design:
   • The articulated structure is a key feature of this truck. It provides enhanced maneuverability, especially in confined spaces or areas with complex terrains. The articulation joint enables the vehicle to make turns more easily, allowing for greater access to different work areas that may be difficult for traditional vehicles to reach.
3. Bucket Lift System:
   • The bucket lift is designed to offer a safe and stable working platform at elevated heights. It has a certain lifting height and outreach, enabling workers to perform tasks such as maintenance, construction, and installation at heights. The lift system is equipped with safety features like overload protection and stability controls to ensure the safety of the operators.
4. Versatile Applications:
   • This type of truck is widely used in various fields, including urban construction, electrical maintenance, street lighting installation and repair, and tree trimming. Its ability to reach high places makes it an essential tool for these types of work.
5. Comfortable and User-Friendly Cab:
   • The cab of the Jmc 4.5 Tonelada Carretilla elevadora u cangilones articulados is designed for operator comfort. It is equipped with features such as a comfortable seat, air conditioning, and good visibility, allowing the operator to work in a relatively comfortable environment for extended periods. Adicionalmente, the control panel is intuitive and easy to operate, reducing the operator’s workload and improving work efficiency.

NOJ

• With a capacity of 4.5 Toneladas, this truck is capable of handling heavy loads. The robust engine provides ample power for both transportation and operation of the bucket lift.
• The articulated design allows for excellent maneuverability in tight spaces and on uneven terrain, ensuring that the truck can access even the most challenging work sites.

• The bucket lift on the Jmc truck is highly advanced. It offers a significant reach and height, enabling workers to access areas that would otherwise be difficult to reach.
• The lift is stable and secure, providing a safe working platform for operators. It is equipped with safety features such as overload protection and emergency stop buttons.

• Built to last, the Jmc 4.5 Ton Articulated Bucket Lift Truck is constructed from high-quality materials. The chassis and body are designed to withstand heavy use and harsh working conditions.
• The truck’s components are engineered for durability, reducing the need for frequent maintenance and minimizing downtime.

• The truck is designed with the operator in mind. The controls are intuitive and easy to use, allowing for efficient operation.
• The cab is comfortable and provides good visibility, enabling the operator to work safely and effectively.

• This bucket lift truck is suitable for a wide range of applications. It can be used in construction, maintenance, telecommunications, and other industries where elevated work is required.
• The truck’s versatility makes it a valuable asset for businesses that need to perform various tasks at different heights.

ESPECIFICACIÓN

A'alajil t'aan yanak
Bix u unidad	4X 2
Batalla	3360milímetro
Type	Carretilla elevadora u cangilones articulados
Vehicle size	5.998×2.0×2.9 meters
Juuch' total	4.495 Toneladas
Vehicle weight	4.365 Toneladas
Voladizo delantero leti' voladizo trasero	1.065/1.573 Metros
Yóol delantera leti' yóol trasera	Front：1385milímetro; Rear：1425milímetro
Engine parameters
Bix kisbuuts'o'	Jiangling JX493ZLQ5
Desplazamiento	2.771L
Potencia wóolis salida	85kW
Potencia wóolis	116 tsíimin u muuk'
Norma emisión	National V
Transmission parameters
Bix u yaantal	Getrag 5-speed
Meyaj ku marchas	5 engranaje
Chassis parameters
Marca le chasis	Jiangling Motors
Serie chasis	Shunda narrow body
Bix chasis	JX1041TG25
Meyaj ku ballestas	7/4+6, 7/5+6
Neumáticos
Meyaj ku neumáticos	6
Especificaciones le neumáticos	7.00R16LT 8PR, 7.00R16LT 8PR, 7.00R16LT 10PR
