• With a load capacity of 6 Toneladas, this truck is capable of handling substantial weights. It can transport heavy equipment, tools, and materials to various job sites, ensuring efficient workflow.
• The robust construction and high-capacity chassis make it suitable for demanding tasks in construction, utilities, and other industries.

• The articulated design allows for excellent maneuverability in tight spaces and on uneven terrain. The truck can turn on a dime, making it ideal for working in congested urban areas or on construction sites with limited space.
• The flexible joint between the cab and the chassis enables the truck to navigate around obstacles and access hard-to-reach areas, increasing its versatility and productivity.

• The bucket lift system is a key feature of this truck. It provides a safe and stable platform for workers to access heights for tasks such as tree trimming, electrical maintenance, and signage installation.
• The bucket can be raised and lowered smoothly, with adjustable height and angle settings to meet different work requirements. The lift mechanism is powered by a reliable hydraulic system, ensuring quick and precise operation.

• Jmc is known for its quality construction, and this truck is no exception. The chassis, body, and components are built to withstand heavy use and harsh working conditions.
• The truck is designed for long-term durability, with features such as reinforced frames, high-quality materials, and reliable mechanical and electrical systems. This ensures minimal downtime and maximum productivity.

• The cab of the Jmc 6 Ton Articulated Bucket Lift Truck is designed for operator comfort and safety. It features a spacious interior, ergonomic seating, and good visibility.
• The truck is equipped with safety features such as rollover protection, seat belts, and emergency stop buttons to ensure the well-being of the operator. Adicionalmente, the bucket lift system has safety locks and overload protection to prevent accidents.

• This truck can be customized to meet specific job requirements. It can be fitted with different attachments and accessories, such as toolboxes, winches, and lighting systems.
• The versatility of the Jmc 6 Ton Articulated Bucket Lift Truck makes it suitable for a wide range of applications, from construction and maintenance to utilities and landscaping.

ESPECIFICACIÓN

A'alajil t'aan yanak
Bix u unidad	4X 2
Batalla	3360milímetro
Type	Carretilla elevadora u cangilones articulados
Vehicle size	7.56X2X2.995 meters
Juuch' total	5.965 Toneladas
Vehicle weight	5.64 Toneladas
Voladizo delantero leti' voladizo trasero	1.075/2.095 Metros
Yóol delantera leti' yóol trasera	Front： 1370milímetro; Rear：1440milímetro
Engine parameters
Bix kisbuuts'o'	Jiangling JX4D30B6H
Desplazamiento	2.892L
Potencia wóolis salida	85kW
Potencia wóolis	116 tsíimin u muuk'
Norma emisión	Euro VI
Transmission parameters
Bix u yaantal	Jiangling 5MTI280Y
Meyaj ku marchas	5 engranaje
Chassis parameters
Marca le chasis	Jiangling Motors
Serie chasis	New Shunda narrow body
Bix chasis	JX1061TSGA26
Meyaj ku ballestas	4/5+6
Neumáticos
Meyaj ku neumáticos	6
Especificaciones le neumáticos	7.00R16LT 12PR.
