Sany 49 Grúa k'uk'umel articulada u tonelada

Rated Lifting Load Mass	16500kg
Full Extended Length of the Lifting Arm	16.8m
Lifting Torque	49t·m

Consulta camiones

Descripción
Comentarios (0)

BREVE

Model Introduction
The folding arm crane models currently produced by Sany Palfinger are all original imports of models that have been sold in Europe for more than 10 years. They have consistent design and quality control standards.
Ultra-low Self-weight
Imported Saab steel plates are used for some key parts. While ensuring the lifting capacity of the crane, this makes the self-weight lighter, increases the cargo carrying capacity for customers, and improves fuel economy.
Design According to Demand
Telescopic jibs, remote controls, winches, auxiliary tools, etc. can be optionally configured according to customers’ needs. There are mature design solutions, enabling one machine to serve multiple purposes.
Standard Filter Configuration
All models in the series are equipped with high-pressure filters as standard, which improves the cleanliness of the oil, reduces crane failures, and extends the service life. There are also super-large span rotating outriggers.
High-speed Movement
In the high-speed movement system of the telescopic arm, the return oil re-enters the pressure circuit instead of flowing back to the control valve. The increased hydraulic pressure makes the cylinder move faster.

NOJ

Leti'e' Sany 49 Grúa k'uk'umel articulada u tonelada is a highly efficient and reliable piece of heavy lifting equipment, meticulously engineered to meet the demanding needs of various industries.

Impressive Lifting Capacity

With a robust 49-ton lifting capacity, this crane is capable of handling substantial loads. Whether it’s hoisting large industrial machinery in a manufacturing plant, moving heavy construction components on a building site, or installing large-scale infrastructure elements, the Sany crane rises to the occasion. The advanced hydraulic system provides a smooth and stable lifting force, ensuring that even heavy and bulky items can be maneuvered with precision and safety.

Flexible Knuckle Boom Design

The knuckle boom design is a standout feature of this crane. Comprising multiple articulated segments, it offers unparalleled flexibility. Operators can easily navigate around obstacles and reach into confined spaces that traditional cranes might find challenging. This makes it ideal for tasks in urban construction sites with limited space, or in industrial settings where the layout is complex. The ability to adjust the boom’s position and angle precisely allows for accurate placement of the load, enhancing overall operational efficiency.

Precise Control System

Equipped with state-of-the-art control mechanisms, the Sany 49-ton knuckle boom crane enables operators to have fine control over its movements. The intuitive controls ensure smooth extension, retraction, and rotation of the boom. Adicionalmente, the crane is integrated with advanced sensors and monitoring systems that provide real-time feedback on the load status, boom position, and operating conditions. This information helps operators make informed decisions, ensuring safe and efficient operations at all times.

Mobility and Maneuverability

Mounted on a sturdy and well-designed carrier, the crane offers good mobility. It can be transported to different job sites with relative ease, reducing the time and cost associated with equipment relocation. Despite its substantial size and lifting capacity, the crane maintains decent maneuverability, allowing it to navigate through construction sites and industrial areas. This adaptability makes it suitable for a wide range of projects, from large-scale infrastructure development to smaller-scale maintenance tasks.

Comprehensive Safety Features

Safety is a top priority in the design of the Sany 49-ton knuckle boom crane. It is equipped with a range of safety features, including load moment indicators to prevent overloading, anti-two-block systems to avoid hook-boom collisions, and adjustable outriggers that provide maximum stability during lifting operations. The operator’s cab is ergonomically designed with excellent visibility and safety features, reducing operator fatigue and enhancing safety during operation.

Durability and Low Maintenance

Constructed using high-quality materials and advanced manufacturing techniques, the Sany 49-ton knuckle boom crane is built to withstand the rigors of heavy-duty use. Its components are engineered for durability, minimizing the frequency of breakdowns and maintenance requirements. This not only reduces downtime but also cuts down on long-term operating costs, making it a cost-effective investment for businesses in need of reliable heavy lifting equipment.

ESPECIFICACIÓN

Lifting Capacity
Maximum Lifting Weight	16500kg
Lifting Torque	49t·m
Rated Lifting Load Mass	16500kg
Rated Lifting Torque	49t·m
Lifting Load Range
Slewing Angle	400°
Maximum Hydraulic Extension	16.8m
Luffing Angle Range	0~75°
Other Parameters
Outrigger Span (Fully Extended)	6.6m
Rated System Pressure	35Mpa
Slewing Torque	5.5t·m
Recommended System Flow Rate	55-80L/min
Number of Hydraulic Telescopic Booms	6
3 Most Important Parameters
Rated Lifting Load Mass	16500kg
Full Extended Length of the Lifting Arm	16.8m
Maximum Hydraulic Extension	16.8m
Maximum Lifting Weight	16500kg
Lifting Torque	49t·m
