Кароткі
Рысы
Спецыфікацыя
Асноўная інфармацыя | |
Drive form | 4X2 |
Калабара | 3300мм |
Тып | Адкатны носьбіт |
Памеры цела | 5.995×2.3×2.345 meters |
Агульная маса | 4.495 тоны |
Вага транспартнага сродку | 3.795 тоны |
Maximum speed | 110km/h |
Пярэдні трэк/задні трэк | Front: 1680мм; rear:1495мм |
Пярэдняя наклад/задняя наклад | 1.125/1.57 meters |
Параметры рухавіка | |
Мадэль рухавіка | Foton Cummins ISF2.8s5129T |
Зрушэнне | 2.78L |
Максімальная конскія сілы | 129 конскія сілы |
Максімальная магутнасць выхаду | 96KW |
Fuel type | Diesel |
Стандарт выкіду | EURO V |
Mounted Equipment Parameters | |
Mounted equipment brand | Chusheng brand |
Lifting capacity | 505kg |
Other | Other: Original factory air conditioner, power windows, remote control key, ABS+EBD, in-car Bluetooth, reversing image, heated rearview mirrors and other multi-functions; Mounted equipment: The upper part is made of imported parts, 3P2A folded stamped flat plate, one towing and two types, bilateral linkage operation device. The plate can bear 3.5 тоны. 40KN hydraulic winch (25-meter steel wire rope), imported multi-way valve and balance valve (Hyder, Italy). The plate is 4.2+1.2 meters long and 2.3 meters wide. It can slide and extend and contact the ground at a small angle. The two sections of the rear towing arm can be telescoped and lifted. The effective length is 1.5 meters. It can lift 2 tons and tow 4 тоны. It is equipped with 1 toolbox, 1 hand washing box, a pair of L-shaped tire holders, 1 pair of towing fork seats, 2 auxiliary trolleys, straps, chain hooks, etc. according to the factory standard. |
Параметры перадачы | |
Мадэль перадачы | WLY5G40 of Wanliyang |
Колькасць перадач | 5 перадачы |
Number of reverse gears | 1 |
Параметры шасі | |
Брэнд шасі | Hyundai Commercial Vehicle |
Серыі шасі | Shengtu H3 |
Мадэль шасі | CHM1043GDC33V |
Rear axle description | 4-ton Dongfeng Dana axle |
Колькасць лісцяных спружын | 4/5+3, 7/7+4, 6/6+4, 8/8+4, 3/9+7 |
Шыны | |
Колькасць шын | 6 кавалкі |
Спецыфікацыя шын | 7.00R16 steel-belted tire |
