FOTON 4×4 Repo Tow Truck

  • 70 Ton Rotator Tow Truck Superstructure

Xasis marka FOTON
Drive mota 4×4
Emission EURO II
Dimensions(L x W x H) 5300×1940×1910 mm
Zaldipen 163 HP
Max under-hoisting capacity 2000 kg
Fully extended max under-hoisting capacity 1413 kg
Kamioi Kontsulta
Kategoriak: Repo Garraioa, Garraioa
  • 70 Ton Rotator Tow Truck Superstructure
Arakatu
  • Kubo-jasogailu artikulatua
  • Zubietako Ikuskapena
  • Zubia Ikuskatzeko Plataforma
  • Zubietako Ikuskapen Unitatea
  • Bucket Truck
  • Isolatutako ontzi-kamioia
  • Garraio Integratua
  • Knuckle Boom Garabia
  • Eskailera igogailua
  • Kargagailua
  • Repo Garraioa
  • Atzera eramailea
  • Kamioi birakaria
  • Alboko Garabia
  • Aireko Igogailu Teleskopikoa
  • Garraioa
  • Garabiarekin garabiarekin
  • Kamioi Garabi Teleskopikoa
  • Deskribapena
  • Additional information
  • Iritziak (0)

LABURRA

The Foton 4×4 Repo Garraioa is not just a small tow truck – it’s a purpose‑built recovery vehicle that brings professional towing capability into places larger wreckers simply cannot go. Designed for light‑duty towing, errepideko laguntza, and commercial fleet operations, this truck combines a true 4×4 off‑road chassis with a fully integrated flatbed and hydraulic under‑lift system.

Kaputxa azpian, a 163 HP turbo‑diesel engine delivers reliable, fuel‑efficient power for daily recovery work. Unlike many pickup‑based wreckers that compromise on real‑world capacity, the Foton 4×4 offers a winch and flatbed both rated at 4,000 kg – enough to handle most cars, SUVs, and light trucks. The hydraulic under‑lift adds another 2,000 kg of lifting capacity (1,413 kg at full extension), giving you two ways to recover a vehicle: carry it on the bed or lift its wheels and tow it away.

What sets this wrecker apart is its go‑anywhere attitude. With compact dimensions (just 5.3 m long), a tight wheelbase, and approach/departure angles of 28°/21°, it maneuvers easily through narrow city streets, parking garages, Eraikuntza guneak, and even unpaved rural roads. The low 7.6° platform angle means you can load low‑clearance vehicles without scraping bumpers – a daily headache for many tow operators.

For fleet owners, the Foton 4×4 Repo Garraioa offers a smart balance of cost, capability, and versatility. It’s small enough to park in a standard bay, nimble enough to respond quickly to calls, and tough enough to earn its keep every single day.

FEATURE

  • Reach breakdowns that others can’t – True 4×4 drive and high ground clearance let you recover vehicles from muddy fields, gravel roads, Eraikuntza guneak, and even light off‑road trails.
  • Two recoveries in one truck – Use the tilt flatbed to carry a vehicle securely, or switch to the hydraulic under‑lift for a faster wheel‑lift. One truck handles two different job types.
  • Real‑world towing capacity – The winch and flatbed both pull up to 4,000 kg – enough for most passenger cars, SUVs, and light commercial vehicles. No guesswork.
  • Low angle, no bumper damage – At just 7.6°, the platform tilts low enough to winch up lowered cars or sports cars without scraping or breaking bodywork.
  • City‑friendly size – At 5.3 metres long, this wrecker fits into tight alleyways, underground parking lots, and residential streets where full‑size tow trucks can’t go.
  • Driver‑focused features – Power steering makes maneuvering feel light and easy; the exhaust brake adds control and safety when towing downhill or on slippery roads.
  • Built for rough roads – Factory all‑terrain tyres and a full‑size spare mean you won’t be the one who gets stuck on the way to a rescue.
  • Simple, reliable diesel power – The 163 HP turbo‑diesel is easy to maintain, fuel‑efficient for fleet use, and delivers torque precisely where a wrecker needs it – at low revs.
  • Ready to work from day one – No expensive add‑ons needed. The flatbed, winch, under‑lift, and full lighting are all integrated at the factory.

ZEHATZA

Kategoria Elementua Parameter
Oinarrizko informazioa Deskribapena Foton 4×4 Pickup wrecker truck
Drive Model 4×4
Vehicle Main Dimensions Dimensions(L x W x H)mm 5300×1940×1910
Wheel base (mm) 3110
Overhang (front/rear) (mm) 955/1235
Ardatz-karga (kg) 2000/3500
Approach/Departure angle(°) 28/21
Weight in KGS Curb Weight 2270
GV.W. 3200
Max. driving speed Max. driving speed(km / h) 90
Motorra Eredu 4F20TC12
Tipo 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Zaldipen 163HP
Emisio estandarra Euro II
Gearbox Gearbox 7 forwards & 1 alderantziz
Clutch Clutch Reinforced diaphragm clutch
Steering Gear Steering Gear Power steering, hydraulic steering with power assistance
Tire Tire 265/65R17, 4pcs + 1 ordezko pneumatikoen
Brakes Brakes Exhaust brake
Platform Organ Min angle(°) 7.6
Max loading capacity(kg) 4000
Winch rating pulling capacity(kg) 4000
Length of steel(m) 21
Hoisting Organ Max under-hoisting capacity(kg) 2000
Fully extended max under-hoisting capacity(kg) 1413

Erlazionatutako mezuak:

  • Howo 4.5Ton Rollback Carrier
    Flatbed Tow Truck Winch System: Cables, Edukiera,…
  • repo tow truck
    Repo Garraioak: Success Stories in Nicaragua
  • 8 Ton Integrated Recovery Tow Truck (2)
    Berreskuratzeko Kamioiak: Errepidean lasaitasuna berreskuratzea
  • repo tow truck (2)
    Repo Garraioak: Berreskuratze azkarrarekin…
  • repo tow truck
    Repo Garraioak: Berreskuratzea eta berreskuratzea eraginkorra
  • FAW 20 Ton Emergency Recovery Integrated Tow Truck Left
    Integrated Tow Truck vs Wheel Lift Tow Truck: Gakoa…
  • 24m Articulated Bucket Lift Truck (4)
    Buying a Tow Truck: Essential Guide for Prospective Buyers
  • 3 Ton White repo Tow Truck (1)
    Seize the Day: Explore the World of Repo Tow Trucks…
Chassis Truck

FOTON

Iritziak

Oraindik ez dago iritzirik.

Izan zaitez berrikusten lehena "FOTON 4×4 Repo Tow Truck” Utzi erantzuna

Lotutako produktuak

Howo T5G 375Horsepower 8X4 Wrecker
Ikuspegi azkarra

Garraioa

Howo T5G 375Horsepower 8X4 Wrecker

Nola 50 Ton Rotator Emergency Wrecker Tow Truck
Ikuspegi azkarra

Garraio Integratua

Nola 50 Tonako kamioi integratua

Nola 50 Ton Road Rescue Wrecking Rotator Tow Truck
Ikuspegi azkarra

Kamioi birakaria

Nola 50 Ton Road Rescue Wrecking Rotator Tow Truck

HOWO Heavy Wrecker Tow Recovery Truck
Ikuspegi azkarra

Garraioa

HOWO Heavy Wrecker Tow Recovery Truck

Shacman Road Rescue Towing Truck Wrecker
