BREF
Le 12-wheelers grue télescopique pour camion produit par Grue de remorquage CSCTRUCK is a robust and versatile piece of heavy machinery designed for substantial lifting tasks. This crane boasts a rated lifting moment of 45 metric tons and can lift to 18,000 kilograms at a radius of 2.5 mètres. It features a maximum outreach of 18.6 meters and utilizes 6 maximum lines on the hook for efficient load handling.
A key feature of this grue télescopique pour camion is its continuous slewing capability, allowing for 360-degree rotation, which enhances maneuverability and operational flexibility. La flèche peut être levée de 0 à 75 degrés, offering a maximum lifting height of 21.5 mètres. The crane’s boom comprises 5 rubriques, with a basic boom length of 6.23 meters that extends to 19 mètres une fois entièrement déployé.
Stability is assured with a fully extended outrigger span of 7.25 mètres, crucial for maintaining balance during heavy lifts. The hydraulic system of the crane is engineered for high performance, with a recommended operating pressure of 32 MPa and a system volume of 100 litres par minute. En plus, the crane requires a 300-liter oil tank capacity to ensure smooth and continuous operation.
Dans l'ensemble, le Grue de remorquage CSCTRUCK 12-wheeler grue télescopique pour camion is a powerful and reliable machine suitable for a variety of lifting applications in construction, logistique, et autres secteurs industriels. Its advanced features and robust construction make it a valuable asset for heavy-duty lifting operations.
CARACTÉRISTIQUES
1. Capacité de levage et portée élevées:
– Capacité de levage nominale: 18,000 kg à 2.5 mètres.
– Hauteur de levage maximale: 21.5 mètres.
– Maximum outreach: 18.6 mètres.
2. Boom Specifications:
– 5-section boom with a basic length of 6.23 mètres.
– Fully extended boom length: 19 mètres.
– Boom raising angle range: 0° to 75°.
3. Système hydraulique efficace:
– Recommended system volume: 100 litres par minute.
– Pression de service: 32 MPa.
– Oil tank capacity: 300 litres.
4. Stability and Support:
– Fully extended outrigger span: 7.25 mètres.
– Designed to provide stable support during lifting operations.
5. Operational Versatility:
– 45-metric-ton rated lifting moment.
– 6 maximum lines of the hook.
– Continuous slewing angle for all rotations, allowing for flexible and efficient positioning.
SPÉCIFICATION
| Données de base | CSCTTC1805-1 |
| Moment de levage nominal | 45 mont |
| Capacité de levage nominale | 18,000 kg (2.5 m) |
| Max. sensibilisation | 18.6 m |
| Max. lignes du crochet | 6 |
| Angle de rotation – continu | All Rotation |
| Angle de levée de la flèche | 0~75° |
| Max. hauteur de levage – the measurement from the ground after the outriggers fully extended | 21.5 m |
| Longueur de la rampe de base | 6.23 m |
| Longueur de la flèche entièrement déployée | 19 m |
| Sections de flèche | 5 |
| Portée des stabilisateurs – entièrement déployé | 7.25 m |
| Volume recommandé pour le système | 100 L/min |
| Pression de service | 32 Mpa |
| Capacité recommandée du réservoir d’huile | 300 L |
