BREF
Le SHACMAN M3000 18-ton grue télescopique pour camion, produit par Grue de remorquage CSCTRUCK, is a versatile and robust lifting solution designed for heavy-duty operations. This crane boasts an impressive rated lifting capacity of 18,000 kg at a 2.5-meter radius, making it suitable for a wide range of lifting tasks. With a maximum outreach of 18.6 mètres et une hauteur de levage maximale de 21.5 mètres, it provides substantial reach and height capabilities for various construction and industrial applications.
Le grue télescopique pour camion features a boom that can be raised from 0 à 75 degrés, offering flexibility in positioning and maneuverability. Its boom system consists of 5 rubriques, with a basic boom length of 6.23 meters and a fully extended length of 19 mètres. La grue’s continuous slewing angle allows for all-around rotation, Amélioration de l'efficacité opérationnelle.
For stability, le SHACMAN M3000 is equipped with a fully extended outrigger span of 7.25 mètres, ensuring secure footing during lifting operations. La grue’s hook can accommodate up to 6 lines, further increasing its versatility and lifting capacity.
The hydraulic system of this crane is designed for high performance, with a recommended operating pressure of 32MPa and a flow rate of 100 litres par minute. To support this hydraulic system, a 300-liter oil tank is recommended, ensuring smooth and uninterrupted operation.
Dans l'ensemble, le SHACMAN M3000 18-ton truck telescopic crane par Grue de remorquage CSCTRUCK combines impressive lifting capabilities with advanced hydraulic performance, making it a reliable choice for demanding lifting tasks in various sectors.
CARACTÉRISTIQUES
1. High Lifting Capacity: La grue a une capacité de levage nominale de 18,000 kg (18 tonnes) at a 2.5-meter outreach, making it suitable for heavy lifting tasks.
2. Extended Reach and Height: The crane offers a maximum outreach of 18.6 mètres et une hauteur de levage maximale de 21.5 mètres, providing significant vertical and horizontal reach for various applications.
3. Configuration de flèche polyvalente: Equipped with a 5-section telescopic boom, the crane can extend from a basic length of 6.23 meters to a fully extended length of 19 mètres, allowing for flexible operation.
4. Système hydraulique efficace: The recommended hydraulic system operates at a volume of 100 liters per minute and a pressure of 32 MPa, ensuring efficient and powerful performance. Le système est soutenu par un réservoir d'huile d'une capacité de 300 litres.
5. Stability and Precision: The crane features a fully extended outrigger span of 7.25 meters and an all-rotation continuous slewing angle. Ce, along with a boom raising angle range of 0 à 75 degrés, ensures stability and precision during lifting operations.
SPÉCIFICATION
| Données de base | CSCTTC1805 |
| Moment de levage nominal | 45mont |
| Capacité de levage nominale | 18,000kg (2.5 m) |
| Max. sensibilisation | 18.6m |
| Max. lignes du crochet | 6 |
| Angle de rotation – continu | All Rotation |
| Angle de levée de la flèche | 0~75° |
| Max. hauteur de levage – the measurement from the ground after the outriggers fully extended | 21.5m |
| Longueur de la rampe de base | 6.23m |
| Longueur de la flèche entièrement déployée | 19m |
| Sections de flèche | 5 |
| Portée des stabilisateurs – entièrement déployé | 7.25m |
| Volume recommandé pour le système | 100L/min |
| Pression de service | 32Mpa |
| Capacité recommandée du réservoir d’huile | 300L |
