BRIEF

The HOWO 10 Tons PALFINGER Telescopic Boom Crane combines the Sinotruk HOWO heavy-duty chassis with the high-performance SANY SPS25000 straight-arm crane. This integrated solution is purpose-built for heavy lifting and cargo transport applications, offering a maximum crane lifting capacity of 10,000 kg. With a 6×4 drive configuration, powered by a SINOTRUK WD615.69 diesel engine delivering 336 HP, the vehicle provides dependable power and durability for demanding logistics, construction, and municipal engineering tasks.

The crane features a 4-section boom that extends from 5.3 m to 18.1 m, providing a maximum lifting height of 20.1 m and a maximum outreach of 17.7 m. It is engineered with high-tensile-strength booms, a 360° continuous slewing mechanism, and a proportional hydraulic control system, enabling precise and efficient lifting operations across a wide variety of job sites.

The truck chassis is equipped with a reinforced cargo body measuring 5,900×2,300×600 mm, making it suitable for simultaneously transporting construction materials, equipment, or industrial goods while completing on-site loading and unloading operations. The combination of excellent road mobility (max speed 90 km/h), robust carrying capacity, and versatile crane performance makes the telescopic boom crane an ideal choice for businesses seeking a single-vehicle solution that eliminates the need for separate transport and lifting equipment.

FEATURES

1. Strong Chassis and High Load Capacity

Heavy-duty 6×4 chassis with front axle capacity of 9,000 kg and tandem rear axles rated at 16,000 kg each, providing exceptional stability and weight distribution for demanding lifting and transport tasks.

2. Purpose-Built Cargo Body

Reinforced cargo box measuring 5,900 mm × 2,300 mm × 600 mm provides ample space for transporting construction materials, equipment, or industrial goods, maximizing the versatility of the integrated lifting and transport solution.

3. High-Performance Crane

The SANY SPS25000 straight-arm crane delivers a maximum lifting capacity of up to 11,000 kg and a rated lifting moment of 25 t·m, capable of handling a wide range of heavy lifting applications.

4. Wide Working Range

Equipped with a 5-section boom extending from a compact 5.3 m basic length to a maximum hydraulic outreach of 17.7 m, achieving a maximum lifting height of 20.1 m for versatile job site reach.

5. Proportional Hydraulic Control System

An advanced proportional hydraulic system provides sensitive controls with accurate positioning for precision lifting jobs, enabling stable movement and the ability to utilize multiple functions simultaneously.

6. Durable and Reliable Construction

Hexagonal boom design offers high strength and torsional rigidity; high-density paint system delivers excellent UV resistance and long-term corrosion protection for extended service life under demanding conditions.

7. Comprehensive Safety Features

Standard equipment includes two working lights for 24-hour safe operation; an optional overload protection system to ensure safe crane operation; a wide outrigger span of 5.6 m ensures optimal stability across all operating configurations.

8. User-Friendly Operation

Crane offers both ground-level and high-seat operating options; 360° continuous slewing capability; and integrated ergonomic design throughout the control system for operator comfort and safety.

9. Efficient Mobility and Transport

Chassis features HW19710 transmission with 10 forward gears and 2 reverse gears, ZF 8118 hydraulic power steering, and a maximum road speed of 90 km/h, allowing efficient movement between job sites.

10. European Quality Standards

Produced according to European Quality Standards by the SANY PALFINGER joint venture, ensuring the best reliability, performance, and safety in the industry.

11. Optimized for Three-Axle Installation

The SPS25000 crane is specifically optimized for mounting on three-axle trucks like the HOWO 6×4 chassis, ensuring proper weight distribution and structural integrity.

12. Low Maintenance Cost

High-pressure return filter protects hydraulic components and prolongs service life; built with high-quality components from globally recognized brands to reduce downtime and total ownership costs.

SPECIFICATION

Category	Item	Parameters
General	Overall dimensions (L x W x H)	9,800×2,600×3,900 mm
	Carriage Size (L x W x H)	5,900×2,300×600 mm
	Wheel base	5,225+1,350 mm
	Wheel track (front/rear)	2022 mm / 1830 mm
	Maximum Driving Speed	90 km/h
Weight	Tare Weight	16,100 kg
	Payload	25,000 kg
	Front axles loading capacity	1×9,000 kg
	Rear axles loading capacity	2×16,000 kg
Engine	Brand	Sinotruck
	Model	WD615.69
	Type	4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, diesel engine
	Horse Power	336 HP
	Emission standard	Euro II
Gearbox	Gearbox Model	HW19710, 10F+2R
Clutch	Clutch Type	Reinforced diaphragm clutch, diameter 430 mm
Steering Gear	Steering Gear Model	ZF 8118, power steering, hydraulic steering with power assistance
Tire	Tire Specification	12R22.5, 10+1 pcs (including one spare tire)
Crane	Model	SANY Palfinger SPS25000
	Max. Lifting Capacity	10,000 kg
	Max. Lifting Moment	25 t·m
	Max. Lifting Height	20.1 m
	Boom Length	5.3-18.1m
	Rotation Angle	360°
	Outrigger Span	5.6 m
	Recommended Volume for the System	60-90 L/min
	Rated Pressure of the Hydraulic System	34 Mpa
	Overall Weight	4,130 kg
