BRIEF

The HOWO-7 10T PALFINGER Telescopic Boom Crane Truck is a heavy-duty truck-mounted crane engineered for demanding material handling, construction, and logistics applications. Built on the legendary SINOTRUK HOWO-7 6×4 chassis—a platform proven in the world’s toughest operating conditions—this truck combines exceptional road performance with a powerful and versatile telescopic boom crane system. The telescopic boom design offers superior vertical lifting precision and a simple, robust structure that has made it the industry workhorse for decades. Designed for one-truck-many-jobs flexibility, it eliminates the need for dedicated lifting equipment on site, allowing operators to transport cargo and perform precision lifting with a single vehicle, whether placing structural steel, unloading heavy equipment, or handling pipes and construction materials.

Under the cab sits the SINOTRUK WD615.69 diesel engine, delivering 336 HP and massive torque for outstanding pulling performance during both transportation and lifting operations. The 6×4 drivetrain provides excellent traction on construction sites, soft ground, and uneven terrain. The HW19710 manual transmission with HW50 power take-off (PTO) ensures smooth power delivery to both the vehicle and the crane system, while BOSCH power steering improves maneuverability in confined working environments. The spacious HW76 cab offers comfortable seating for two operators, making it ideal for long-distance transportation and extended working hours.

The defining feature of this truck is the PALFINGER SPS25000B-F telescopic boom crane, a world-class loader crane engineered by PALFINGER, one of the world’s leading crane manufacturers. With a 25 tonne-metre rated lifting moment and a 10-ton maximum lifting capacity, the crane delivers outstanding lifting performance across a wide range of applications. Its four-section telescopic boom provides a 14.0-meter maximum outreach and 16.1-meter lifting height, allowing operators to complete high-reach lifting tasks without repositioning the truck. Compared with knuckle boom cranes, the wire rope hoist and telescopic boom design offer greater vertical positioning accuracy, making the telescopic boom crane especially suitable for structural installation, equipment placement, and high-elevation material handling. Continuous 360° slewing and a 0–75° boom elevation angle further enhance operational flexibility.

---

FEATURES

1. Chassis & Powertrain – Built for Heavy Haulage and Hard Use

• SINOTRUK HOWO-7 6×4 heavy-duty chassis provides outstanding stability, durability, and load-carrying capacity for demanding applications.
• SINOTRUK WD615.69 diesel engine (336 HP) delivers reliable power and high torque for both transportation and lifting operations.
• HW19710 manual transmission (10F+2R) ensures smooth gear shifting and precise vehicle control.
• HW50 direct-drive PTO supplies dependable hydraulic power to the crane system.
• 12.00R20 steel radial tyres provide excellent traction and durability on various road conditions.
• Reinforced axle configuration and 41,000 kg GVW ensure excellent stability under heavy loads.
• BOSCH hydraulic power steering reduces driver fatigue and improves maneuverability.

2. PALFINGER Telescopic Boom Crane – Precision and Power

• 25 tonne-metre rated lifting moment delivers excellent lifting performance across the full working range.
• 10-ton lifting capacity enables efficient handling of steel beams, pipes, machinery, and other heavy cargo.
• 14.0-meter working outreach expands the crane’s operating area while minimizing vehicle repositioning.
• 16.1-meter lifting height supports construction, bridge maintenance, and industrial applications.
• Four-section telescopic boom provides smooth and precise hydraulic extension.
• Continuous 360° slewing enables efficient lifting from virtually any direction.
• 0–75° boom elevation angle accommodates both low-level and high-level lifting operations.
• The wire rope hoist delivers superior vertical lifting precision, making it ideal for structural assembly, equipment installation, and precision material handling.

3. Hydraulic System – Smooth and Responsive

• High-pressure hydraulic system delivers strong lifting performance with smooth and responsive operation.
• Optimized hydraulic flow improves boom speed and overall working efficiency.
• Load-holding valves prevent boom drift and maintain load stability during lifting.
• Proportional control valves ensure accurate and jerk-free crane movements.

4. Safety Systems – Comprehensive Protection

• Hydraulic overload protection prevents lifting beyond the crane’s rated capacity.
• Load-holding safety valves secure cylinders during operation.
• Emergency stop system allows immediate shutdown when required.
• Wide-span hydraulic outriggers provide excellent stability during heavy lifting.
• Integrated fail-safe control system minimizes operational risks and protects both personnel and equipment.

5. Operator Convenience – Comfort and Control

• Ergonomically arranged control levers simplify crane operation and reduce operator fatigue.
• Floor-mounted control station provides excellent visibility of the lifting area.
• Comfortable HW76 cab improves driver comfort during extended operations.
• Multiple hook reeving configurations provide flexibility for different lifting requirements.

6. Durability & Versatility – Built for the Long Haul

• The proven HOWO-7 platform delivers exceptional durability with global parts availability.
• The telescopic boom design features fewer moving parts than articulated cranes, reducing maintenance costs.
• Heavy-duty drum braking system ensures reliable stopping performance under full load.
• Suitable for construction, logistics, mining, municipal engineering, and industrial material handling.
• Reinforced cargo body allows the transportation of steel, pipes, machinery, and other oversized materials alongside crane operations.

SPECIFICATION

Category	Item	Parameters
General	Drive Type	6×4, LHD
	Overall dimensions (L x W x H)	10,500×2,550×3,850 mm
	Carriage Size (L x W x H)	6,500×2,500×600 mm
	Wheel base	4,600+1,350 mm
	Maximum Driving Speed	90 km/h
Weight	Tare Weight	15,400 kg
	G.V.W.	41,000 kg
Cabin	Make/Model	SINOTRUK/HW76
	Number of seats	2
Engine	Brand	Sinotruck
	Model	WD615.69
	Type	4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, diesel engine
	Displacement	9.726 L
	Horse Power	336 HP
	Emission standard	Euro II
Transmission	Make/Model	SINOTRUK/HW19710 Gearbox + HW50 direct-drive PTO
	Type	MT
	Number of Gears	10F+2R
Axle	Front Axle Make/Model	SINOTRUK/VGD95
	Front Axle Rating	9.5T(Drum)
	Rear Axle Make/Model	SINOTRUK/MCX16ZG
	Rear Axle Rating	2×16T(Drum)
Steering Gear	Make	BOSCH
Tire	Tire Size	12.00R20 steel radial tires (mixed tread pattern, 18PR)
	Tire Nos.	10+1 pcs (including one spare tire)
Crane	Make/Model	PALFINGER/SPS25000B-F
	Rated Lifting Moment	25 mt
	Rated Lifting Capacity	10000 kg (2.5 m)
	Max. Outreach	14.0 m
	Max. Lines of the Hook	6
	Slewing Angle	Continuous
	Boom Raising Angle	0 ~ 75°
	Max. Lifting Height	16.1 m
	Boom Length	5.3 ~ 14.3m
	Boom Sections	4
	Outrigger Span (fully extended)	5600 (mm)
	Recommended Flow Rate	60 ~ 90 L/min
	Operating Pressure	31 Mpa
	Recommended Oil Tank Capacity	200 L
	Crane Weight	3820 kg (Floor control)
