BRIEF

The ISUZU GIGA 50T Rotator Tow Truck is a high-performance heavy-duty tow truck engineered for complex roadside rescue, accident recovery, and large commercial vehicle towing operations. Built on a reinforced multi-axle chassis, this tow truck delivers outstanding lifting capacity, superior stability, and excellent maneuverability, making it ideal for demanding highway, industrial, and emergency recovery tasks.

At the core of this heavy-duty tow truck is a high-capacity hydraulic rotator boom with 360° continuous rotation. This advanced rotating system allows operators to execute precise lifting and recovery operations in confined or challenging environments without the need to reposition the vehicle. Such flexibility significantly improves efficiency and reduces recovery time, especially in high-traffic or restricted job sites.

The dual heavy-duty winch system provides powerful and controlled pulling performance, enabling the rotator wrecker truck to recover overturned trucks, buses, trailers, and heavy machinery safely and efficiently. Whether performing upright recoveries, under-lifts, or complex extractions, this professional tow truck is designed to handle extreme loads with confidence.

For maximum operational stability, the vehicle features a reinforced structural body and hydraulic stabilizer outriggers. These outriggers create a wider support base during lifting operations, ensuring enhanced balance and safety under high-load conditions. Multiple integrated tool compartments are strategically designed for organized storage of chains, rigging, and recovery accessories, helping towing operators maintain an efficient workflow on-site.

Combining strength, precision engineering, and long-term reliability, the ISUZU GIGA 50T Rotator Tow Truck stands out as a dependable and powerful heavy-duty tow truck solution for professional towing and recovery service providers.

---

FEATURES

Core Capabilities

Heavy-Duty Load Capacity: Equipped with a 50-ton towing capacity and 40-ton lifting capacity, specifically engineered for heavy commercial vehicle recovery.

Dual Winch System: Features 2 x 25-ton hydraulic winches, delivering a total pulling force of 50 tons to handle complex rescue scenarios.

360° Continuous Rotation: The full 360° rotating superstructure allows for rescue operations from any angle without repositioning the chassis.

Chassis & Powertrain

ISUZU GIGA Professional Chassis: Built on a dedicated ISUZU GIGA 8×4 chassis with a wheelbase of 2100+4325+1370mm, ensuring stability under extreme loads.

High-Power Engine: Powered by the 6WG1-TCG62 engine, delivering 382 kW (520 HP) with a displacement of 15,681ml, compliant with EURO VI emission standards.

Reliable Transmission: Equipped with a FAST 12-speed gearbox (12 forward + 2 reverse gears) for versatile torque delivery across various terrains.

High-Capacity Tires: Fitted with 12 units of 315/80R22.5 tires(including 1 spare), supporting a Gross Vehicle Weight (GVW) of 40,000 kg.

Body & Operating Systems

High-Strength Boom: Utilizes a three-section hexagonal boom design for enhanced bending resistance and stability. When fully extended, it offers a maximum lifting capacity of 6.5 tons and an effective working length of 12,210 mm.

Multi-Functional Trailer Arm: Comes with a three-section rear trailing arm and is equipped with various types of steel forks (trailer forks, steel lug forks, towing forks) to adapt to different vehicle types.

Dual-Side Operation: Features dual-side linkage hydraulic controls, allowing operators to work from the safest side based on site conditions, improving visibility and safety.

Safety & Auxiliary Features

Spring Brake System: Utilizes a reliable air brake system with spring brakes (spring-applied, air-release) to ensure safe parking and emergency braking.

Wheel Locking Device: Standard tire locking device prevents the recovered vehicle from swaying or slipping during transport.

Securing Chains: Comes with 2 bundle chains for safely securing loads.

Warning System: Equipped with a yellow engineering warning lamp to ensure operational safety at night and in adverse weather conditions.

---

SPECIFICATIONS

CATEGORY	ITEM	PARAMETER
General	Drive Type	8×4
	Overall Dimensions (L×W×H)	11,500 × 2,550 × 3,600 mm
	Wheelbase	2100 + 4325 + 1370 mm
	Gross Vehicle Weight (GVW)	40,000 kg
	Curb Weight	35,000 kg
	Maximum Speed	105 km/h
Cab	Model	VC61 5X
	Number of Seats	3
	Seat Rows	1.5 Rows
	Instrument & Controls	Central locking, electric doors & windows, multifunction steering wheel, multifunction LCD instrument panel
Engine	Make	ISUZU
	Model	6WG1-TCG62
	Horsepower	382 kW / 520 HP
	Max Torque / Speed	2250 N·m / 900–1300 rpm
	Emission Standard	EURO VI
	Displacement	15.681 L
	Fuel Type	Diesel
Transmission	Make	FAST
	Type	Manual
	Gearbox	12 Forward + 2 Reverse
Tires	Type	315/80R22.5
	Quantity	12 + 1
Brake System	Type	Air Brake
Winch System	Quantity	2 pcs
	Rated Pulling Capacity	25,000 kg × 2
	Steel Cable Length	45 m
Hoisting System	Rated Under-Pulling Capacity	50,000 kg
	Rated Under-Hoisting Capacity	40,000 kg
	Fully Extended Max Under-Hoisting Capacity	6,500 kg
	Max Under-Hoist Useful Length	12,210 mm
Boom System	Boom Structure	Three-section hexagonal boom with three-section rear trailing arm
	Operation System	Double-sided hydraulic linkage operation
