SUMMARY
FEATURES
The Howo 16T XCMG Telescopic Boom Crane is a specialized heavy-duty truck designed for efficient and safe transportation of containers. Here are some of its key features:
- High-Performance Engine: Equipped with a powerful engine with a capacity of 6-8L, this truck achieves a maximum horsepower of 350hp, ensuring efficient operation and long-distance transportation.
- Durable and Reliable Construction: The truck-mounted crane boasts a robust construction with a boom length of 5.8-20m and a lifting speed of 60m/min, making it suitable for heavy-duty operations.
- Advanced Safety Features: The truck crane features an amplitude angle of 0-75, a rated lifting weight of 15000/2.2kg/m, and a rated lifting moment of 350 kN · m, ensuring safe and stable lifting operations.
- User-Friendly Support: Comprehensive after-sales service is provided, including video technical support, online support, and free spare parts, ensuring assistance whenever needed.
- Versatile and Efficient Operation: Designed for high-altitude operation and suitable for various industries, including construction, mining, and logistics, making it an ideal choice for business needs.
- High Load Capacity: The Howo Sidelifter Truck is capable of lifting and transporting containers weighing up to 40 tonnes, thanks to its strong hydraulic system.
- Advanced Hydraulic System: The hydraulic system is a complex network of components that work together to ensure the truck can lift and transport heavy cargo efficiently.
- Efficient Control System: The control system includes a remote control panel for precise and efficient operation, and an automatic weight checking system to ensure safe transportation within weight limits.
- Safety Features: The truck comes with stabilizers for stability during lifting or carrying heavy cargo and safety sensors that detect the ground level, reducing the likelihood of accidents.
- Production Details: The chassis is made from high-quality steel, and the truck is fitted with a powerful engine and an advanced hydraulic system for lifting and transporting capabilities.
These features make the Howo 16T XCMG Telescopic Boom Crane a reliable and efficient choice for heavy-duty container transportation.
SPECIFICATIONS
| Basic Information | |
| Drive Type | 8X4 |
| Wheelbase | 2,100 + 4,300 + 1,350 mm |
| Vehicle Type | Telescopic Boom Crane |
| Vehicle Dimensions | 12,000 × 2,550 × 3,950 mm |
| Front Overhang/Rear Overhang | 1,500 mm / 2,575 mm |
| Engine Parameters | |
| Engine Model | Weichai WP8.350E61 |
| Displacement | 7.8 L |
| Maximum Output Power | 257 kW / 350 HP |
| Emission Standard | Euro VI |
| Fuel Type | Diesel |
| Maximum Torque / Speed | 1,400N·m / 1,200-1600rpm |
| Transmission Parameters | |
| Transmission Model | Sinotruk HW9-speed |
| Number of Gears | 9F+1R |
| Chassis Parameters | |
| Chassis Brand | Sinotruk HOWO |
| Chassis Series | HOWO TX |
| Rear Axle Description | MAN 12T |
| Number of Leaf Springs | 11/11/12 |
| Gear Ratio | 4.63 |
| Tires | |
| Number of Tires | 12 |
| Tire Specification | 1.00R20 18PR |
| Crane Parameters | |
| Crane Brand | XCMG |
| Crane Model | GSQS400-4 |
| Maximum Lifting Capacity | 16000Kg |
| Maximum Lifting Torque | 420kN·m |
| Max. Hydraulic Boom Length | 20.7m |
| Outrigger Span | 2484mm-8404mm |
